Using the internal web pages
7. USING THE INTERNAL WEB PAGES
The C-54 E web pages offer a user-friendly interface for configuring module settings and
viewing live video images over the network.

7.1. System Requirements

A PC with a standard web browser installed.
An IP connection between the PC and the C-54 E (see section 5.1).

7.2. Login

To log on to the internal web server
1. Start your web browser.
2. Enter the C-54 E's IP address as URL in the Address Bar.
If your network configuration is correct you are directed to the login page.
If the login page does not display correctly you may need to enable JavaScript in your
web browser (see Appendix 3).
In the Login section, click
3.
Figure 7.1 Entering the module IP address into a browser's Address Bar
Figure 7.2 C-54 E Login page
LOGIN.
- 25 -
