Web User Interface; Ii-2-1 General Setup - Draytek Vigor2860 User Manual

W e b U s e r I n t
W e b U s e r I n t
I I - 2 - 1 G e
I I - 2 - 1 G
This page provides you the general settings for LAN. Click LAN to open the LAN settings page
and choose General Setup.
There are six subnets provided by the router which allow users to divide groups into different
subnets (LAN1 – LAN6). In addition, different subnets can link for each other by configuring
Inter-LAN Routing. At present, LAN1 setting is fixed with NAT mode only. LAN2 – LAN6 can be
operated under NAT or Route mode. IP Routed Subnet can be operated under Route mode.
Available settings are explained as follows:
Item
General Setup
148
e r f a c e
e r f a c e
n e r a l S e t u p
e n e r a l S e t u p
Description
Allow to configure settings for each subnet respectively.
Index - Display all of the LAN items.
Status- Basically, LAN1 status is enabled in default.
LAN2 –LAN6 and IP Routed Subnet can be observed by
Vigor2860 Series User's Guide
