if disabled.
Distance: distance between the horizontal axe of the unit and the detector; in
●
millimetres.
Length: detector's length; in millimetres.
●
DelayTime: the minimum time that must go by, from the moment the lights go
●
red, until the infringement is made, to generate a valid incidence; in
milliseconds.
FirstLoop (Loop1): coordinates (in the 5 megapixel image ) of the detector's first
●
loop, using a Region structure.
SecondLoop (Loop2): coordinates (in the 5 megapixel image) of the detector's
●
second loop, using a Region structure.
TrafficLightId: the traffic light identifier used for the red state sign. If no traffic
●
light has been configured, but a digital input, its value will be -1.
RedInput: the identifier of the digital input used for the red state sign. If no
●
digital input has been configured, but a traffic light, its value will be -1.
AmberInput: the identifier of the digital input used for the amber sign.
●
digital input has been configured (because a traffic light will be used, or because
no amber signal will be used) its value will be -1.
IsVideoEnabled (isVE): true if video generation in the incidences is enabled, false
●
otherwise.
PreVideoTimeMs (PreVideoT): time that the start of video capturing will be
●
advanced since the first picture; in miliseconds.
PostVideoTimeMs (PostVideoT): time that the stop of video capturing will be
●
delayed since the third picture; in miliseconds.
LastPictureDelayTimeMs (LastPictureD.): time that the last picture of the
●
incidence will be delayed; in miliseconds.
Version 1:
87
Header
16
Loop2
The field "LastPictureDelayTimeMs" doesn't exist. The rest of fields have the same meaning of
version 2.
