Focus: calculated digital focus coefficient; -1 if not calculated.
●
NumDetectors: number of configured detectors.
●
DetectorsStatus (Dstatus): status of loops for each configured detector.
●
Described with 40 consecutive integers,
Detector's location will follow configuration order, and each position will detail
loop status bitwise. The least significant bit corresponds to the first loop.
Possible values: 1 presence, 0 free.
NumRedLights: number of configured traffic lights.
●
RedLights: status of each configured traffic light. Described with 3 bytes, only
●
the first NumRedLights will be used. They will follow the same configuration
order. Possible values: 0 "red state", other value "any other state".
Inputs: status of the 2 digital inputs. Each one of the first 2 bits corresponds to
●
the status of an input, being the least significant bit for the input zero. Possible
values: 1 enabled, 0 disabled.
Outputs: status of the 8 digital outputs. Each one of the first 8 bits corresponds
●
to the status of an output, being the least significant bit for the output zero.
Possible values: 1 enabled, 0 disabled.
ImageSize: total size of the captured image; in bytes.
●
Length: size of the transferred packet of the image; in bytes.
●
Buffer: data packet. Only valid the first Length bytes.
●

4.7.7. UnitTasksQuery

Query to receive the status of the tasks a unit must perform.
Query
Type: 38
●
Message Data: no message data.
●
Answer
Type: 70
●
Message Data:
●
SendInputChanges (SInp): if true, notifications to central system about changes
●
Quercus Technologies
149
only used the first NumDetectors.
1
SInp
