Value: value that the condition uses on the comparison.
●
4.5.13. OutputActuator
Describes a digital output actuator.
The structure corresponds to the version 1. Check 5. Communications protocol (old versions)
to see the older versions.
Id: unique identifier of the output actuator.
●
Operator (Op): operator type that defines ouptut actuator's logical behaviour.
●
0: all conditions have to be true to activate the digital output.
○
1: one or more conditions have to be true to activate the digital output
○
OutputId (OId): digital output identifier that corresponds to the actuator.
●
Time: time that the actuator keeps the digital output active; in milliseconds.
●
NumConditions (NCo): number of conditions that belongs to the output actuator.
●
Conditions: descriptions of the conditions that belongs to the output actuator;
●
see the 4.5.12. OutputActuatorCondition structure.

4.6. Event messages

4.6.1. InputChanged
Indicates that one digital input has changed.
Type: 0
●
Message Data:
●
Bit: identifier of the digital input that changed its value.
●
Value (Val): new value.
●
4.6.2. Notification
Indicates that a notification of type "Code" has been received.
Quercus Technologies
139
4 1 1
Id Op OId
4
1
Time
Conditions
NCo
1 1
Bit Val
