QuercusVL Programming Manual
configured as central system, they can come from any address. The answer will always be sent
to the IP address that sent the last correct Login message, and the destiny port will be the one
specified in that message (see down below).

4.9.1. Ping

Sends an answer query to the configuration system. Its main goal is to check that at the IP
and port where the message is sent, there is a configuration system running. It is not needed
to complete a successful Login message, to get answer to this message.
Query
Type: 51
●
Message Data:
●
Port: port where the configuration system must send the answer.
●
Answer
ACK/NAK
4.9.2. Login
Obtains access to unit's configuration system.
Query
Type: 128
●
Message Data:
●
Password: configuration system's password.
●
Port: port where the configuration system must send the answer.
●
Answer
Quercus Technologies
160
4
Port
64
Password
4
Port
