UNOCODE PRO
1.3 M
AIN WORKING PARTS
E
H
I
D
F
V
T
S
C
Fig. 6
A - master switch
B - keyboard
C - display
D - clamp - cutter side
D1 - clamp - optical reader
E - clamp knob
E1 - optical reader clamp knob
F - key gauge - cutter side
F1 - key gauge - optical reader side
H - cutter
I - cutter shield
L - optical reader
N - emergency button
O - 3rd axis
P - IN/OUT port
Q - serial port
Q1 - USB port
R - Y axis connector
S - X axis carriage
T - Y axis carriage
U - protective shield
U2 - vacuum systems connector
V - swarf tray
6
B
Copyright Silca 2017
Operating manual - English
U
L
E1
D1
F1
Q
Q1
N P O R
A
