Operating manual

1.1 Main working parts

A
J1
J
C B
A - carriage movement lever
B - carriage handle
C - clamp carriage
D - carriage release pin (tilting)
E - tracer point
E1 - tracer point spring locking knob
F - cutting tool
G - tracer point ring nut
H - main switch
H1 - warning light (power)
6
E E1 G N
L
D
Copyright Silca 2014
K
Fig. 6
J - clamp
J1 - clamp handle
K - motor start switch
L - swarf tray
M - motor
N - cutting tool cover
P - brush/belt cover
R - power supply socket
S - brush
FASTBIT
H1
M
P
R
H
F S
