Configuration
Table 3-9 Multi-Unit Config Menu
Item Description
Allows customization of the default device name.
Dev Name
This setting is optional and does not affect operation.
See "Setting the Device Name" on page 3–41.
Allows setting of a unique unit number in a multiple-unit
Dev Number
system. See "Setting the Device Number" on page 3–42.
For a split-phase system: For a multi-unit system to
Inverter
operate, one Conext XW+ must be configured to
Mode
SplitPhMaster and the rest as SplitPhSlave, otherwise
a system-wide fault is asserted.
For a single-phase system: For a multi-unit system to
operate, one Conext XW+ must be configured to
1PhMaster and the rest as 1PhSlave, otherwise a system-
wide fault is asserted.
Before setting up a single-phase system, perform the steps
in "Converting 120 V/240 V Split-Phase to 120 V Single-
Phase" in the Conext XW+ Inverter/Charger Installation
Guide.
For a three-phase system: See "Three-Phase Configuration" on page 3–43.
Select to display the Connections menu.
Connections
See "Connections Menu" on page 3–45.
3–40
Default Range
n/a n/a
00 00–31
SplitPhMaster For single-
phase, three-
wire models:
SplitPhMaster,
SplitPhSlave
1PhMaster SplitPhMaster,
SplitPhSlave
n/a n/a
