Inverter Settings Menu; Charger Settings Menu; Custom Settings Submenu - Conext XW+ 6848 NA Owner's Manual

Inverter Settings Menu

Charger Settings Menu

Custom Settings Submenu

975-0240-01-01
Item
Low Batt Cut Out
LBCO Hysteresis
LBCO Delay
High Batt Cut Out
Search Watts
Search Delay
Item
Batt Type
Batt Capacity
Max Chg Rate
Charge Cycle
Default Batt Temp
ReCharge Volts
Absorb Time
Chg Block Start
Chg Block Stop
a.When Custom battery selected, two sub-menus appear: Custom Settings and
LithiumIon
b.Setting the battery capacity to 0 will reset the charging current to its default val-
ues. Zero Ah battery capacity implies there is no absorption exit current criteria
and absorption only exits when the absorption timer (default 3 hrs, range 1 min-
8 hr) expires.
Item
Eqlz Support
Eqlz Voltage
a
Bulk Voltage
a
Absorb Voltage
a
Float Voltage
Default Setting Range
44 V 36–48 V
2 V 0-10 V
10s 0–600s
65 V 58–70 V
50 W 25–255 W
2s 1–25s
Default Setting Range
Flooded Flooded, Gel, AGM,
Custom
440 Ah
0–10000 Ah
100% 5–100%
2-Stage 2-Stage, 3-Stage
Warm Cold, Warm, Hot
50 V 40.0–54.0 V
180 min 1–480 min
12:00 AM 12:00 AM–11:59 PM,
00:00–23:59
12:00 AM 12:00 AM–11:59 PM,
00:00–23:59
Default Setting Range
Enabled Enabled, Disabled
64.0 V 54.0–64.0 V
57.6 V 54.2–64.0 V
56.8 V (Gel)
57.2 V (AGM)
57.6 V 40.0–64.0 V
56.8 V (Gel)
57.2 V (AGM)
54.0 V 50.0–64.0 V
55.2 V (Gel)
53.6 V (AGM)
Default Settings and Ranges
Step Size
0.1
0.1
1
0.1
5
1
Step Size
n/a
a
b 1
1
n/a
n/a
0.1
1
1
1
Step Size
n/a
0.1
0.1
0.1
0.1
B–3
