Table 2-2 Meters Screen
Screen Item Description
AC frequency connected to the Conext XW+ AC2 terminals.
AC2 Freq
Power consumed by the AC loads attached to AC OUT, in volt-amps and watts.
Load Power
AC voltage and current supplied from L1 to the AC loads on AC OUT.
Load L1
AC voltage and current supplied from L2 to the AC loads on AC OUT.
Load L2
AC frequency supplied to the AC loads on AC OUT.
Load Freq
Operating state of the Conext XW+. For more information, see Table 2-1 on page 2–15.
State
Charging current and battery voltage.
DC
Battery temperature as read by the BTS, connected to the Conext XW+. If the BTS is
Batt Temp
connected to a different device on the Xanbus network, please see the Meters screen for
that device for temperature data. All Xanbus devices on the Xanbus network will share
temperature data for temperature compensated charging. However, the temperature is
only displayed on the meters screen for the device with the BTS installed. The BTS which
is monitoring the device displaying the highest temperature will take priority. If the BTS is
not installed, it shows NotAvailable.
NOTE: If other battery-based power conversion Xanbus-enabled devices are connected
to the network, a BTS must be separately installed for each of those devices. See the
installation guide of the device for instructions.
