Conext XW+ 6848 NA Owner's Manual page 65

975-0240-01-01
Bulk Stage
Battery
Voltage
Recharge
Voltage
Battery
Current
Max Charge
Rate
Figure 3-5 Two-Stage Charging Cycle
Absorption Stage
(Boost Stage)
Absorption Voltage
2-Stage Charge
Custom Charge
Boost
Timer
1hr fixed
Max Absorb Time - Dflt 3 hrs
(adjustable 1 min - 8 hrs )
Charger Settings Menu
Return to
Bulk Stage
Time
Absorption Exit Current
Threshold = 2% of
programmed AH capacity
Time
3–17
