Multi-Unit Config Menu

975-0240-01-01
High Batt Temp Activates the auxiliary output when the battery temperature
rises above Hi Batt Temp for the trigger delay time. The auxiliary output turns off
when the battery temperature falls below the clear setting for the Clear Delay
time. Battery temperature is measured with a battery temperature sensor. Do not
use this setting if a battery temperature sensor is not installed. With this setting,
the auxiliary output can turn on a fan to vent the battery compartment.
Fault Activates the auxiliary output when a fault occurs. The auxiliary output
clears when the fault is cleared.
State of Charge (SoC) This feature works in conjunction with the Conext
Battery Monitor. This auxiliary output is triggered when the state of charge falls
outside of the range of 25-90% of total battery charge.
ADVANCED CONFIGURATION HAZARD
Advanced menu settings should be used by qualified personnel only.
Three phase operation should be configured by qualified personnel only.
Consult with the local utility before enabling Conext XW+ sell mode or grid
support functions.
Do not change these settings unless you are under the supervision and
direction of qualified personnel.
Failure to follow these instructions can result in death or serious injury.
The Multi-Unit Config menu configures the Conext XW+ to operate as a part of
a multi-unit installation.
When installing a multi-unit system, each setting on the Multi-Unit Config menu
(except for Dev Name) must be configured for each Conext XW+ in the system. The
settings should be configured in the following order:
• Dev Number
• Inverter Mode
• Connections
Note: Accessing this menu automatically places the Conext XW+ in Standby
mode and de-energizes the circuits on inverter output. When entering the Multi-
Unit Config menu, the unit identifies itself by flashing the front panel lights. After
exiting the Multi-Unit Config menu, the Conext XW+ returns to operating mode
and the front panel lights stop flashing.
WARNING

Multi-Unit Config Menu

3–39
