Conext XW+ 6848 NA Owner's Manual page 117

Table 4-6 Fault Messages
Fault
Number Message
F1 AC Output Under
Voltage
F2 AC Output Over
Voltage
F17 Relay(s) Welded
F18 Relay(s) Welded
F19 Relay(s) Welded
F20 Relay(s) Welded
F21 Relay(s) Welded
F22 Relay(s) Welded
975-0240-01-01
Fault Type Cause
Escalating AC under voltage
Auto Fault. shutdown at 108 V. The
Must occur inverter has shut down to
3 times in protect the loads.
2 minutes
before
becoming a
manual fault.
Escalating AC over voltage
Auto Fault. shutdown at 135 V. The
Must occur inverter has shut down to
3 times in protect the loads.
30 seconds
before
becoming a
manual fault.
Manual The AC1 L1 transfer relay
is bad or an AC source
was wired directly to the
AC output.
Manual The AC1 L2 transfer relay
is bad or an AC source
was wired directly to the
AC output.
Manual The AC2 L1 transfer relay
is bad or an AC source
was wired directly to the
AC output.
Manual The AC2 L2 transfer relay
is bad or an AC source
was wired directly to the
AC output.
Manual An unidentified transfer
relay is bad or an AC
source was wired directly
to the AC output.
Manual An unidentified L1
transfer relay is bad or an
AC source was wired
directly to the AC output.
Faults and Warnings
Solution
Clear the fault and attempt
restart. If problem persists,
call customer service.
Clear the fault and attempt
restart. If problem persists,
call customer service.
Disconnect the inverter's
output wiring. If error
continues, have unit serviced.
Disconnect the inverter's
output wiring. If error
continues, have unit serviced.
Disconnect the inverter's
output wiring. If error
continues, have unit serviced.
Disconnect the inverter's
output wiring. If error
continues, have unit serviced.
Disconnect the inverter's
output wiring. If error
continues, have unit serviced.
Disconnect the inverter's
output wiring. If error
continues, have unit serviced.
4–19
