Available Conext XW+ Accessories

Operation

Bidirectional Theory of Operation

975-0240-01-01
Accessory
Conext XW+ Power Distribution Panel
Conext XW+ Power Distribution Panel
(Without AC Breakers)
Conext XW+ Conduit Box
Conext XW+ Connection Kit for INV2
INV3 PDP
Conext System Control Panel
Conext Automatic Generator Start
Conext MPPT 60 150 Solar Charge
Controller
Conext MPPT 80 600 Solar Charge
Controller
Conext ComBox
Conext Battery Monitor
Conext XW+ PDP 120/240V 60A
Breaker Kit
The Conext XW+ is a grid forming device consisting of a bidirectional inverter/
charger. It is capable of inverting DC power into AC power and controlling the
voltage and frequency of its inverter output. It will power external loads attached
to AC OUT (See Figure 1-2, "Inverting of DC to AC Connected to AC OUT" on
page 1–4).
The Conext XW+ is also capable of charging external batteries by converting AC
power into DC power (See Figure 1-3, "Charging External Batteries and
Supplying AC Out with AC Passthrough from AC1 Grid " on page 1–5). The
Conext XW+ accepts AC power through connection AC2 for charging batteries,
usually from a generator (See Figure 1-4, "Charging External Batteries and
Supplying AC Out with AC Passthrough from AC2 Generator" on page 1–5).
The Conext XW+ will convert externally sourced DC power into AC power for
export to the utility grid attached to its AC1 connection (See Figure 1-5,
"Converting Excess Available DC power for Export to Utility Grid (AC1) and AC
Out" on page 1–6).
The Conext XW+ has an internal automatic transfer switch (K1, K2) which allows
either AC1 or AC2 to be connected to the inverter input, but not both at the same
time (See Figure 1-1, "Connection Points and Major Power Conversion
Components of Conext XW+ " on page 1–4). This allows shared AC energy
during charging or to directly passthrough from AC1, or AC2, to AC Out.
Part Number
865-1015-01
865-1014-01
865-1025-01
865-1020-02
865-1050-01
865-1060-01
865-1030-1
865-1032
865-1058
865-1080-01
865-1215-01
Operation
1–3
