Custom and Lithium Ion Battery Settings Sub Menus

975-0240-01-01
BATTERY TYPE AND SETUP HAZARDS
Incorrect battery configurations or settings for battery types can lead to
dangerously high battery temperature, fire and explosion. To avoid damaging
your batteries during charging or equalization, and to minimize the risk of fire
or explosion consult battery manufacturer's documentation before setting
battery parameters and follow the battery manufacturer's recommended
settings.
• Always use and connect the Battery Temperature Sensor (BTS).
• Always verify that the configured battery type matches the battery type
being used.
• Custom battery settings should be configured by qualified personnel only.
• When using Lithium-Ion batteries, ensure that the battery pack being used
includes a Battery Management System (BMS) with safety controls.
Failure to follow these instructions can result in death or serious injury.
Further details about Lithium Ion support can be found in the document Lithium
Ion Application Note (Document Part Number: 976-0319-01-01) available at
http://solar.schneider-electric.com.
ADVANCED CONFIGURATION HAZARD
Advanced menu settings should be used by qualified personnel only.
Three phase operation should be configured by qualified personnel only.
Consult with the local utility before enabling Conext XW+ sell mode or grid
support functions.
Do not change these settings unless you are under the supervision and
direction of qualified personnel.
Failure to follow these instructions can result in death or serious injury.
The Custom Settings sub menu can be viewed if Custom is selected as the Batt
Type. This menu allows you to adjust charging and equalization voltage for
batteries with specifications that fall outside the default settings for the battery
types the Conext XW+ offers. You can also adjust the temperature compensation
constant for the battery temperature sensor on this menu.
Note: The default settings for configuring a custom battery type are based on the
default settings for a flooded battery type.
WARNING
WARNING
Charger Settings Menu
3–21
