Conext XW+ 6848 NA Owner's Manual page 45

Table 2-1 Conext XW+ Home Screen States
Conext XW+
Status Displayed When...
The Conext XW+ supports the utility grid when there is AC input on AC1 and the
Load Shaving
current required to power the loads rises above the Load Shave Amps setting between
the Load Shave Start and Load Shave Stop times set on the Grid Support menu.
However, AC charging including force charging is disabled during these times. AC
charging is enabled when battery voltage falls below [LBCO + 1V]. For an illustration,
see Figure 3-7 on page 3–28.
When load shaving, the Conext XW+ uses stored battery energy to reduce the peak
load on the AC1 input by providing the difference between the actual load current and
the Load Shave Amps setting. The Conext XW+ enters this state only when Grid
Support is enabled, the load shave time window is valid and the load draw exceeds
the Load Shave Amps setting. The battery voltage must also be between
ReCharge Volts +0.5 V and the Grid Supp Volts setting. See "Grid Support
Settings" on page 3–26.
Search mode is enabled and the Conext XW+ is standing by, waiting to begin
Search
inverting. See "Using Search Mode" on page 3–9.
The Conext XW+ is grid-tied and is exporting energy to the utility grid on AC1. Both
SellToGrid
Grid Support and Sell must be enabled in order to sell power back to the utility. See
Table 3-1, "Conext XW+ Setup Menu" on page 3–2 and "Grid Support Settings" on
page 3–26. All configurations must comply with local and national electrical codes.
The unit has been placed in standby mode using the Mode setting on the Conext SCP
Standby
Setup menu, the Standby button on the Conext SCP, or the Standby key press
(
STARTUP
The AC connected to the AC1 or AC2 input is passing directly through the Conext
Passthru
XW+ to the loads attached to AC Out. The batteries are not being charged in this state.
Equalization has been turned on and the Conext XW+ is equalizing the batteries after
Equalize
completing a full charge cycle.
975-0240-01-01
/ and Equalization) on the inverter information panel.
SHUTDOWN
Monitoring Operation with the Conext SCP
2–17
