Grid Support Menu; Gen Support Menu; Aux Menu - Conext XW+ 6848 NA Owner's Manual

Grid Support Menu

Gen Support Menu

Aux Menu

975-0240-01-01
Item
Grid Supp Volts
Sell
b
Max Sell Amps
Load Shave
Load Shave Amps
c
Load Shave Start
Load Shave Stop
Sell Block Start
Sell Block Stop
a.The setting for Grid Supp Volts must be greater or equal to LBCO+2 V. For example, if
LBCO is 44 V then the minimum Grid Supp Volts is 46 V.
b.This setting is restricted to the selected external AC1 breaker size.
c.When Load Shaving is enabled, if Load Shave Start and Load Shave Stop are set to the
same time, the Conext load shaves continuously.
Setting
GenSupp Mode
GenSupp Amps
Item
Manual Aux
Active Lvl
a
Trig Src
Trigger Level—
b
LowBattV
Clear Level—LowBattV
Trigger Level—
HighBattV
Clear Level—HighBattV
Default Range
a
53.0 V 42.0–70.0 V
Disabled Disabled, Enabled
27 A (XW+ 6848), 0–27 A (XW+ 6848),
20 A (XW+ 5548) 0–20 A (XW+ 5548)
Disabled Disabled, Enabled
48 A 0–48 A
12:00 AM 12:00 AM–11:59 PM,
00:00–23:59
12:00 AM 12:00 AM–11:59 PM,
00:00–23:59
12:00 AM 12:00 AM–11:59 PM,
00:00–23:59
12:00 AM 12:00 AM–11:59 PM,
00:00–23:59
Default Range
Disabled Enabled, Disabled
48 A 0–48 A
Default Range
ManualOff ManualOn, ManualOff,
Automatic
ActiveHigh ActiveHigh, ActiveLow
LowBattV LowBattV, HighBattV,
LowBattTemp,
HighBattTemp, Fault
46.0 VDC 40.0–58.0 VDC
48.0 VDC 40.0–58.0 VDC
56.0 VDC 48.0–64.0 VDC
52.0 VDC 48.0–64.0 VDC
Default Settings and Ranges
Step Size
0.1
n/a
1
n/a
1
1
1
1
1
Step Size
n/a
1
Step Size
n/a
n/a
n/a
0.1
0.1
0.1
0.1
B–5
