Conext XW+ 6848 NA Owner's Manual page 118

Troubleshooting
Table 4-6 Fault Messages
Fault
Number Message
F23 AI Over
Frequency
F24 AI Under
Frequency
F25 AI Over
Frequency
F26 AI Under
Frequency
F27 AI L1 Over
Voltage
F28 AI L2 Over
Voltage
F29 AI L1L2 Over
Voltage
F30 AI L1L2 Over
Voltage
F31 AI L1 Over
Voltage
F32 AI L2 Over
Voltage
F33 AI L1L2 Over
Voltage
F34 AI L1 Under
Voltage
4–20
Fault Type Cause
Automatic Over-frequency anti-
islanding, caught by the
AC qualification limit.
Automatic Under-frequency anti-
islanding, caught by the
AC qualification limit.
Automatic Over-frequency anti-
islanding.
Automatic Under-frequency anti-
islanding.
Automatic Over-voltage anti-
islanding, fast
disconnect, 135 VAC.
Automatic See F27.
Automatic Over-voltage anti-
islanding fault, caught by
the qualification limit,
voltage difference
between L1 and L2.
Automatic Over-voltage anti-
islanding, fast
disconnect, 270 V.
Automatic Over-voltage anti-
islanding, slow
disconnect, 130 V.
Automatic Over-voltage anti-
islanding, slow
disconnect, 130 V.
Automatic Over-voltage anti-
islanding, slow
disconnect, 260 V.
Automatic Under-voltage anti-
islanding, slow
disconnect, 108 V.
Solution
No action required. The
inverter stops selling and
disconnects from the grid.
When the fault clears, a
five-minute timer begins
counting down. The inverter
does not sell again until grid
voltage and frequency are
within range for five minutes.
See F23.
See F23.
See F23.
See F23.
See F23.
See F23.
See F23.
See F23.
See F23.
See F23.
See F23.
975-0240-01-01
