Firmware options
5. Apply the configuration changes:
a. Select Schedule from the Save drop-down menu.
b. Specify the schedule options:
6. Configure the buffer time for the sensor to ensure the desired amount of data is stored when
an alarm occurs. For information, see

Enable continuous monitoring on analog input

Note The Connect Sensor firmware must be upgraded before continuous monitoring can be enabled
on the analog or digital input. For information, see
1. Follow the standard process to configure an Analog 4-20mA Current Loop or Analog Voltage
Input. For instructions, see
2. The analog input must be enabled. Verify that the Interface Enable (ena) option is set to On.
3. Verify that the Continuous Monitoring Enable (mon) option is set to On.
4. Click Save.
5. Apply the configuration changes:
a. Select Schedule from the Save drop-down menu.
b. Specify the schedule options:
Digi Connect® Sensor User Guide
Apply changes during the next wake cycle:
n
i. Select Immediate.
ii. Select the Schedule Offline check box.
iii. Click Schedule.
Apply changes on a specific date and time in the future:
n
i. Select One-Time.
ii. Choose a date and time from the drop-down menus.
Note The change is applied during the wake cycle after the date
and time you specify.
iii. Select the Schedule Offline check box.
iv. Click Schedule.
Connect Sensor downloads and applies configuration changes the next time
it connects to Remote Manager.
Configure the buffer time for continuous
Enable and configure analog
Apply changes during the next wake cycle:
n
i. Select Immediate.
ii. Select the Schedule Offline check box.
iii. Click Schedule.
Apply changes on a specific date and time in the future:
n
CSENSE Continuous Monitoring firmware
CSENSE Continuous Monitoring
inputs.
monitoring.
firmware.
130
