Get started
Item Name
9 Input/Output (I/O) interface
10 Cable glands

Set up a Connect Sensor

Complete all of the tasks in this section in order to set up a Connect Sensor.
1. Assemble Connect Sensor
2. Configure the cellular connection
3. Check the cellular connection
4. Wire the I/O sensors
Digi Connect® Sensor User Guide
Description
Wire analog or digital input and output sensors or power
to this interface. For more information, see the
Connect Sensor I/O Wiring Guide.
Thread sensor cables through these openings into
Connect Sensor.
Set up a Connect Sensor
