Digital Input option definitions

The following table provides Remote Manager definitions for Connect Sensor Digital: Input options. For details about setting these options, see
and configure a digital input.
Option Description
Interface Enables or disables the digital input source.
Enable
High Alarm Enables or disables high alarm reports for the digital input source. When enabled, sends an alarm report when the pin is
high.
Low Alarm Enables or disables low alarm reports for the digital input source. When enabled, sends an alarm report when the pin is
low.
Delta Low Enables or disables delta low alarm reports for the digital input source. When enabled, sends an alarm report for a
Alarm falling transition.
Delta High Enables or disables delta high alarm reports for the digital input source. When enabled, sends an alarm report for a
Alarm rising transition.
Enables or disables the device to monitor a digital input during sleep mode. When enabled, wakes the device when the
Rising
digital input changes from low voltage to high voltage (rising edge) and reports the value to Remote Manager with the
Edge Wake
other sensor and device data.
Enables or disables the device to monitor a digital input during sleep mode. When enabled, wakes the device when the
Falling
digital input changes from high voltage to low voltage (falling edge) and reports the value to Remote Manager with the
Edge Wake
other sensor and device data.
Enable Enables or disables the internal pull-up resistor to drive a logic level voltage. For example, use this to drive a logic
pullup voltage across a mechanical switch to read the value (open or closed) of the mechanical switch.
Sensor Specifies description of the sensor for this input source.
description
Enable
Range Default
On/Off Off
On/Off Off
On/Off Off
On/Off Off
On/Off Off
On/Off Off
On/Off Off
On/Off Off
Text Empty
