NLS-HR15

(NLS-HR1550-30)

Hand-held Barcode Scanner

User Guide

Table of Contents

Summary of Contents for Newland NLS-HR1550-30

Page 1 NLS-HR15 (NLS-HR1550-30) Hand-held Barcode Scanner User Guide...
Page 2 All pictures in this manual are for reference only and actual product may differ. Regarding to the product modification and update, Fujian Newland Auto-ID Tech. Co., Ltd. reserves the right to make changes to any software or hardware to improve reliability, function, or design at any time without notice.
Page 3: Revision History
Revision History Version Description Date V1.0 Initial release. December 25, 2011 V1.1 Moved the Enter/Exit Setup barcodes to page header and footer. August 10, 2012 1. Added the Timeout between Decodes (Same Barcode) programming feature for the Sense and Continuous modes. V1.2 March 19, 2013 2.
Page 4 Table of Contents Revision History ..................................- 3 - Preface ......................................1 Introduction ................................... 1 Chapter Description ................................1 Document Set ..................................2 Chapter 1 Getting Started ................................3 Introduction ................................... 3 Unpacking ..................................... 3 Scanner ....................................3 Data Port ....................................4 Connect HR15 to a Host ...............................
Page 5 Default Settings ................................... 21 Restore Factory Default Settings ..........................21 Operating Mode Options ..............................22 Scan Mode ..................................23 Manual Mode ................................23 Auto Mode ..................................24 Blink Mode ................................... 26 Sense Mode ................................. 27 Continuous Mode ................................. 30 Delayed Sense Mode ..............................32 Command Trigger Mode ..............................
Page 6 Introduction ................................53 Acquire Scanned Data ............................53 VID/PID ................................. 54 IBM SurePOS (Table-Top) ............................55 IBM SurePOS (Hand-Held) ............................55 Chapter 5 Prefix & Suffix ................................. 56 Introduction ..................................56 Prefix Sequence .................................. 56 Custom Prefix ..................................57 Enable/Disable Custom Prefix ............................. 57 Set Custom Prefix ................................
Page 7 Set Length Range for AIM 128 ............................. 71 EAN-8 ....................................72 Restore Default Settings .............................. 72 Enable/Disable EAN-8 ..............................72 Set Code ID ................................. 73 2-Digit Add-On Code ..............................74 5-Digit Add-On Code ..............................75 EAN-8 Extension ................................76 Transmit Check Digit ..............................76 EAN-13 ....................................
Page 8 5-Digit Add-On Code ..............................92 Transmit Preamble Character ............................93 UPC-E Extension ................................. 93 UPC-A ....................................94 Restore Default Settings .............................. 94 Enable/Disable UPC-A ..............................94 Set Code ID ................................. 95 Transmit Check Digit ..............................96 Transmit Preamble Character ............................96 2-Digit Add-On Code ..............................
Page 9 Enable/Disable Matrix 2 of 5 ............................116 Set Code ID ................................117 Check Digit Verification .............................. 118 Set Length Range for Matrix 2 of 5 ..........................119 Industrial 25 ..................................120 Restore Default Settings ............................120 Enable/Disable Industrial 25 ............................120 Set Code ID ................................
Page 10 Set Code ID ................................141 Check Digit Verification .............................. 142 Set Length Range for Code 93 ..........................143 Code 11 ..................................... 144 Restore Default Settings ............................144 Enable/Disable Code 11 ............................. 144 Set Code ID ................................145 Check Digit Verification .............................. 146 Set Length Range for Code 11 ...........................
Page 11 Chapter 7 Data Formatter ..............................167 Introduction ..................................167 Add a Data Format ................................167 Programming with Barcodes ............................167 Programming with Serial Commands ......................... 169 Enable Data Format ................................170 Change Data Format for a Single Scan ..........................170 Enable/Disable Data Formatter ............................
Page 13: Preface
Preface Introduction This manual provides detailed instructions for setting up and using the NLS-HR1550-30 hand-held barcode scanner (hereinafter referred to as “HR15 corded scanner” or “the scanner”). Chapter Description  Chapter 1, Getting Started : This chapter gives a general description of HR15 corded scanner including its technical parameters.
Page 14: Document Set
NLS-HR1550-30 User Guide Describes how to use and set the HR15 corded scanner. 1D Barcode Scanner Firmware Update Utility Describes how to update the firmware in 1D barcode scanners User Guide with this tool developed by Newland.
Page 15: Chapter 1 Getting Started
2D stacked symbologies such as PDF417 and MicroPDF417. Based on the technology independently developed by Newland, HR15 corded scanner is able to deliver rapid image acquisition and accurate decoding; it can provide customers with best services. HR15 corded scanner boasts the ergonomical design that ensures easy and comfortable operation.
Page 16: Data Port
Data Port Data Port Fig. 1-2...
Page 17 Data port pinout 1 (factory default): Definition Type Description Not connected Not connected Power+ (+5V) RS-232 Output RS-232 Input Flow control signal Ground USB signal Data port pinout 2: Definition Type Description CLK1 Keyboard clock signal DATA1 Keyboard data signal Power+ (+5V) RS-232 Output RS-232 Input...
Page 18: Connect Hr15 To A Host
Connect HR15 to a Host HR15 corded scanner must be connected to a host device in actual application, such as PC, POS or any intelligent terminal with USB or RS-232 or PS/2 port, using a communication cable (USB or RS-232 or PS/2 cable). ...
Page 19: Use Usb Cable
Use USB Cable Fig. 1-3 Connect HR15 corded scanner to a Host through a USB cable with RJ45 and USB connectors: Plug the RJ45 connector into the data port (see Fig.1-1) on the scanner. Plug the USB connector into the USB port on the Host. Use RS-232 Cable Fig.
Page 20: Use Ps/2 Cable
Use PS/2 Cable Fig. 1-5 Connect HR15 corded scanner to a Host through a PS/2 cable equipped with PS/2 and RJ45 connectors, PS/2 female socket and power jack (Only applicable to HR1550-33): Plug the RJ45 connector into the data port (see Fig.1-1) on the scanner. Plug the PS/2 connector into the PS/2 port on the Host.
Page 21: Remove Communication Cable
Remove Communication Cable Fig. 1-6 Get an appropriate needle or a straightened paper clip and then follow the steps below: Disconnect the power adapter from mains and the scanner if there is one. Insert the needle into the disassemble hole (Fig. 1-6). Pull out the cable slowly from the scanner while pressing the needle in.
Page 22: Maintenance
Maintenance  The scan window should be kept clean.  Do not scratch the scan window of the device.  Use soft brush to remove the stain from the scan window.  Use soft cloth to clean the window, such as eyeglass cleaning cloth. ...
Page 23: Depth Of Field
Depth of Field Fig. 1-7...
Page 24: Specifications
Specifications Performance Light Source 620nm visible red LED Image Sensor Linear imager Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, Symbologies ISBN, Code 93, UCC/EAN-128, GS1 Databar, PDF417, MicroPDF417, etc. ≥ 4 mil Resolution ±55°@ 0°Roll and 0°Skew Pitch ±30°@ 0°Pitch and 0°Skew Scan Angle*...
Page 25: Dimensions
Dimensions Side View Fig. 1-8 Front View Fig. 1-9...
Page 26: Top View
Top View Fig. 1-10 Scanning Instructions When the HR15 corded scanner is in the Manual mode (default), you can follow the steps below to scan a barcode: Hold down the trigger. Then the scanner will project a red aiming beam. Aim the red beam across the center of barcode, as shown in Fig.1-11.
Page 27 Scan Angle The scanner is designed to function within a certain range of scan angles. Any unreasonable deviation may cause decoding failure. Scan angles of the scanner:  Pitch ：± 55° , 0° Roll and 0° Skew (Fig. 1-12)  Roll ：±...
Page 28: Chapter 2 General Settings
**【Enter Setup】 Chapter 2 General Settings Introduction There are two ways to configure the HR15 corded scanner: Barcode programming and command programming. Barcode Programming The HR15 corded scanner scans a series of barcodes to program features. In the following sections, we will explain the available options and features and provide the barcodes to program them.
Page 29: Programming Barcode/ Programming Command/Function
**【Enter Setup】 Programming Barcode/ Programming Command/Function The figure above is an example that shows you the programming barcode and command for the Enter Setup function: 1. The Enter Setup barcode. 2. The Enter Setup command. 3. The function that can be enabled by using the programming barcode or command listed above. 4.
Page 30: Use Of Command
**【Enter Setup】 Use of Command Based on serial port communication, programming commands can be composed of printable ASCII characters, 0x20 (space) through 0x7D (“}”). Programming Mode Before configuring the HR15 corded scanner through serial communication, the device must enter the programming mode; in such mode, the device will only accept and process commands and respond accordingly.
Page 31 **【Enter Setup】 If a command involves parameter(s), they shall be combined as per the rule. For example: The combined commands for appending terminating character suffix 0x0D (CR),0x0A (LF) to the scanned data and saving the settings: “#99904112;#99900000;#99900015;#99900000;#99900012;#99900020;”. 【Exit Setup】...
Page 32: Configuration Process Flow
**【Enter Setup】 Configuration Process Flow 【Exit Setup】...
Page 33: Default Settings
**【Enter Setup】 Default Settings Restore Factory Default Settings Scanning the Reset Scanner barcode can restore the scanner to the factory default settings. You may need to reset your scanner when: 1. scanner is not properly configured so that it fails to decode barcodes; 2.
Page 34: Operating Mode Options
**【Enter Setup】 Operating Mode Options 【Power Off 】【Test Mode 】【Deep Sleep Mode 】【Reboot Scanner】【Light Sleep Mode 】 Note: 1. The scanner that has been turned off in this way cannot be awakened. To turn it back on, disconnect it from the host device and reconnect it.
Page 35: Scan Mode
**【Enter Setup】 Scan Mode Manual Mode Manual Mode (default): A trigger pull activates a decode session. The decode session continues until the barcode is decoded or you release the trigger or the decode session timeout expires (default: 15 seconds; programmable). **【Manual Mode】...
Page 36: Auto Mode
**【Enter Setup】 Auto Mode Auto Mode: Pressing the trigger activates a decode session. The decode session continues until the barcode is decoded or the decode session timeout expires (default: 15 seconds; programmable). The scanner automatically starts one session after another until you press the trigger a second time. 【Auto Mode】...
Page 37 **【Enter Setup】 Decode Session Timeout: This parameter sets the maximum time decode session continues during a scan attempt. The default timeout is 15s. To program this parameter, scan the Decode Session Timeout barcode and the numeric barcodes. To find the numeric barcodes, see the “Digit Barcodes”...
Page 38: Blink Mode
**【Enter Setup】 Blink Mode Blink Mode: The scanner automatically activates a decode session. The decode session continues until the barcode is decoded or the decode session timeout expires (100ms; non-programmable). When a decode session is completed, the scanner waits until the timeout between decodes expires (default: 1s, programmable) and then starts next session. The scanner continues to work in this pattern.
Page 39: Sense Mode
**【Enter Setup】 Sense Mode Sense Mode: The scanner activates a decode session every time when it detects a change in ambient illumination (excluding the situation when change is detected before the timeout between decodes expires). Decode session continues until the barcode is decoded or the decode session timeout expires. Pressing the trigger can also activate a decode session.
Page 40 **【Enter Setup】 Sensitivity specifies the degree of acuteness of the scanner’s response to changes in ambient illumination. The higher the sensitivity, the lower requirement in illumination change to trigger the scanner. You can select an appropriate degree of sensitivity that fits the ambient environment. By default, High Sensitivity is enabled. **【High Sensitivity】...
Page 41 **【Enter Setup】 Timeout between Decodes (Same Barcode): This parameter sets the minimum time between decodes for the same barcode. It protects against accidental rereads of the same barcode. It is programmable in 0.1s increments from 0s to 12s. If you want to stop the scanner from rereading the same barcode, set this parameter to 127. The default timeout is 1.6s. To program this parameter, scan the Timeout between Decodes (Same Barcode) barcode, the numeric barcode(s) and the Save barcode.
Page 42: Continuous Mode
**【Enter Setup】 Continuous Mode Continuous Mode: The scanner automatically activates decode sessions one after another. The decode session continues until the barcode is decoded. For a good read, the scanner waits until the timeout between decodes expires and then starts next session. For a bad read, the scanner continues to decode the barcode until it is decoded. Same barcode cannot be reread before the timeout between decodes (same barcode) expires.
Page 43 **【Enter Setup】 Timeout between Decodes: This parameter sets the time period between the end of one decode session and the start of next session. It is programmable in 0.5s increments from 0s to 7.5s. The default timeout is 1s. To program this parameter, scan the Timeout between Decodes barcode and the numeric barcodes.
Page 44: Delayed Sense Mode
**【Enter Setup】 Delayed Sense Mode Delayed Sense Mode: The scanner automatically activates a decode session when it detects a change in ambient illumination. The decode session continues until the barcode is decoded or the decode session timeout expires. When a decode session is completed, the scanner waits 200ms and then starts to monitor ambient environment until it detects a change to trigger next decode session.
Page 45: Command Trigger Mode
**【Enter Setup】 Command Trigger Mode Command Trigger Mode: The scanner activates a decode session when receiving the command string of “$$$$#99900035;%%%%” or scanning the Start Trigger Simulation barcode. The decode session continues until the barcode is decoded, or the scanner receives the command string of “$$$$#99900036;%%%%” or scans the Stop Trigger Simulation barcode.
Page 46: Hands-Free Scanning (Hardware Version: V1.3 Or Higher)
**【Enter Setup】 Hands-free Scanning (Hardware Version: V1.3 or higher) Inserting the scanner in the stand enables the scanner to switch from its current scan mode to the Sense mode. The red LED on the scanner illuminates to indicate that the Sense mode is enabled. And the scanner is ready for hands-free scanning.
Page 47: Security Setup
**【Enter Setup】 Security Setup This parameter specifies the number of times to decode a barcode during a scan attempt. The higher the security level, the lower the error rate and decoding efficiency. By default, security is set to be level 1. **【Set Security Level to 1】...
Page 48: Good Read Beep
**【Enter Setup】 Good Read Beep By default, the scanner emits a medium-pitched loud beep that lasts 150ms after good read. 【Do Not Beep After Good Read】【Medium-Pitched Medium-Loud Beep】【High-Pitched Loud Beep】【Medium-Pitched Low Beep】【High-Pitched Medium-Loud Beep】【Low-Pitched Loud Beep】【High-Pitched Low Beep】...
Page 49 **【Enter Setup】 **【Set Beep Length to 150ms】【Set Beep Length to 50ms】【Set Beep Length to 100ms】【Exit Setup】...
Page 50: Decode Area And Output Interval
**【Enter Setup】 Decode Area and Output Interval You can set the number of barcodes allowed to be read per scan. By default, the Read One Barcode Nearest to the Center Per Scan option is enabled. You can also set the decoded data output interval. By default, output interval is 0ms. 【Read 2 Barcodes Per Scan】...
Page 51: Other Settings
**【Enter Setup】 Other Settings Temporary Mute 【Enable Temporary Mute】【Disable Temporary Mute】 Note: Temporary Mute is only applicable to decode beep and will be disabled after you reboot the scanner. 【Exit Setup】...
Page 52: Chapter 3 Inquiry Command
**【Enter Setup】 Chapter 3 Inquiry Command Introduction You can scan one of the barcodes below to inquire the scanner information. The results will be sent to the Host. 【Inquire all Information】【Inquire the Manufacturing Date】【Inquire the Firmware Version】【Inquire the Model Number】【Inquire the Serial Number】...
Page 53: Chapter 4 Communication Settings
**【Enter Setup】 Chapter 4 Communication Settings RS-232 Interface Baud Rate When the scanner is connected to the Host via serial port, you need to set communication parameters (including baud rate, parity check, data bit and stop bit) to match the host device. Baud rate is the number of bits of data transmitted per second.
Page 54 **【Enter Setup】【38400】【57600】【115200】【Exit Setup】...
Page 55: Parity Check
**【Enter Setup】 Parity Check By default, the None option is enabled. **【None】【Even】【Odd】 Stop Bit By default, the 1 Stop Bit option is enabled. **【1 Stop Bit】【2 Stop Bits】【Exit Setup】...
Page 56: Flow Control
**【Enter Setup】 Flow Control By default, the No Flow Control option is enabled. **【No Flow Control】【CTS Flow Control】【RTS Flow Control】【RTS_CTS Flow Control】【Exit Setup】...
Page 57: Data Bit
**【Enter Setup】 Data Bit By default, the 8 Data Bits option is enabled. **【8 Data Bits】【8 Data Bits, No Parity, 2 Stop Bits】【8 Data Bits, No Parity, 1 Stop Bit】【8 Data Bits, Even Parity , 2 Stop Bits】【8 Data Bits, Even Parity, 1 Stop Bit】...
Page 58: Usb Interface
**【Enter Setup】 USB Interface By default, the USB HID-KBW option is enabled. USB HID-KBW **【USB HID-KBW】【Exit Setup】...
Page 59: Keyboard Layout
**【Enter Setup】 Keyboard Layout By default, the 1-US (English) option is enabled. **【1 – US (English)】【7 - Italy】【2 - Japanese】【8 - Norway】【3 - Denmark】【9 - Spain】【4 - Finland】【10 - Turkey Q】【5 - France】【11 - UK】...
Page 60: Inter-Character Delay
**【Enter Setup】 Inter-Character Delay Inter-character Delay: 00-15 (16 levels), corresponding to 0ms (default), 5ms, 10ms, …, 75ms, in 5ms increments. 【Inter-Character Delay】 Convert Case By default, the No Case Conversion option is enabled. **【No Case Conversion】【Convert All to Lowercase】【Convert All to Uppercase】...
Page 61: Emulate Alt+Keypad
**【Enter Setup】 Emulate ALT+Keypad This feature allows any ASCII character (0x00 - 0xFF) to be sent over the numeric keypad no matter which keyboard type is selected. Since sending a character involves multiple keystroke emulations, this method appears less efficient. The following options are available: ...
Page 62: Function Key Mapping
**【Enter Setup】 Function Key Mapping When Function Key Mapping is enabled, function characters (0x00 - 0x1F) are sent as ASCII sequences over the keypad. For more information, see ASCII Function Key Mapping Table in Appendix. 【Enable Function Key Mapping】 **【Disable Function Key Mapping】 Example: Barcode data 0x16 Enable Function Key Mapping Ctrl+V...
Page 63: Emulate Numeric Keypad
**【Enter Setup】 Emulate Numeric Keypad When this feature is disabled, sending barcode data is emulated as keystroke(s) on main keyboard. To enable this feature, scan the Emulate Numeric Keypad barcode. Sending a number (0-9) is emulated as keystroke(s) on numeric keypad, whereas sending other character like “+”, “_”, “*” , “/” and “.” is still emulated as keystrokes on main keyboard.
Page 64: Usb Com Port Emulation
**【Enter Setup】 USB COM Port Emulation 【USB COM Port Emulation】【Exit Setup】...
Page 65: Hid-Pos
**【Enter Setup】 HID-POS Introduction The HID-POS interface is recommended for new application programs. It can send up to 56 characters in a single USB report and appears more efficient than keyboard emulation. Features:  HID based, no custom driver required. ...
Page 66: Vid/Pid
USB uses VID (Vendor ID) and PID (Product ID) to identify and locate a device. The VID is assigned by USB Implementers Forum. Newland’s vendor ID is 1EAB (Hex). A range of PIDs are used for each Newland product family.
Page 67: Ibm Surepos (Table-Top)
**【Enter Setup】 IBM SurePOS (Table-Top) 【IBM-SurePOS (Table-Top)】 IBM SurePOS (Hand-Held) 【IBM-SurePOS (Hand-Held)】【Exit Setup】...
Page 68: Chapter 5 Prefix & Suffix
**【Enter Setup】 Chapter 5 Prefix & Suffix Introduction After a successful barcode reading, a string containing numbers, letters or symbols will be returned. In real applications, barcode data may be found insufficient for your needs. You may wish to include additional information such as barcode type, data acquisition time or delimiter in data being scanned.
Page 69: Custom Prefix
**【Enter Setup】 Custom Prefix Enable/Disable Custom Prefix If custom prefix is enabled, you are allowed to append to the data a user-defined prefix that cannot exceed 11 characters. By default, custom prefix is disabled. For example, if barcode data is “123” and custom prefix is “AB”, the Host will receive “AB123”. **【Disable Custom Prefix】...
Page 70: Aim Id Prefix
**【Enter Setup】 AIM ID Prefix AIM (Automatic Identification Manufacturers) ID defines symbology identifier (For the details, see the “AIM ID Table” section in Appendix). If AIM ID prefix is enabled, the scanner will add the symbology identifier before the scanned data after decoding.
Page 71: Custom Suffix
**【Enter Setup】 Custom Suffix Enable/Disable Custom Suffix If custom suffix is enabled, you are allowed to append to the data a user-defined suffix that cannot exceed 11 characters. By default, custom suffix is disabled. For example, if barcode data is “123” and custom suffix is “AB”, the Host will receive “123AB”. **【Disable Custom Suffix】...
Page 72: Terminating Character Suffix
**【Enter Setup】 Terminating Character Suffix Enable/Disable Terminating Character Suffix A terminating character such as carriage return (CR) or carriage return/line feed pair (CRLF) can only be used to mark the end of data, which means nothing can be added after it. By default, terminating character suffix is enabled. 【Disable Terminating Character Suffix】...
Page 73: Set Terminating Character Suffix
**【Enter Setup】 Set Terminating Character Suffix To set a terminating character suffix, scan the Set Terminating Character Suffix barcode, the numeric barcodes that represent the hexadecimal value of desired terminating character(s) and the Save barcode. By default, terminating character 0x0D,0x0A is enabled. 【Terminating Character 0x0D】...
Page 74: Chapter 6 Symbologies
**【Enter Setup】 Chapter 6 Symbologies Introduction Every symbology (barcode type) has its own unique attributes. This chapter provides programming barcodes for configuring the scanner so that it can identify various barcode symbologies. It is recommended to disable those that are rarely used to increase the efficiency of the scanner.
Page 75: Code 128
**【Enter Setup】 Code 128 Restore Default Settings Scan the barcode below to restore all parameters in Code 128 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Code 128】 Enable/Disable Code 128 Code 128 is enabled by default.
Page 76 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Code 128. To set the Code ID, scan the Set Code ID for Code 128 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 77: Set Length Range For Code 128
**【Enter Setup】 Set Length Range for Code 128 The scanner can be configured to only decode Code 128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes Code 128 barcodes with either the minimum or maximum length.
Page 78: Ucc/Ean-128
**【Enter Setup】 UCC/EAN-128 Restore Default Settings Scan the barcode below to restore all parameters in UCC/EAN-128 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of UCC/EAN-128】 Enable/Disable UCC/EAN-128 UCC/EAN-128 is enabled by default.
Page 79 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for UCC/EAN-128. To set the Code ID, scan the Set Code ID for UCC/EAN-128 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 80: Set Length Range For Ucc/Ean-128
**【Enter Setup】 Set Length Range for UCC/EAN-128 The scanner can be configured to only decode UCC/EAN-128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes UCC/EAN-128 barcodes with either the minimum or maximum length.
Page 81: Restore Default Settings
**【Enter Setup】 AIM 128 Restore Default Settings Scan the barcode below to restore all parameters in AIM 128 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of AIM 128】 Enable/Disable AIM 128 AIM 128 is disabled by default.
Page 82 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for AIM 128. To set the Code ID, scan the Set Code ID for AIM 128 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 83: Set Length Range For Aim 128
**【Enter Setup】 Set Length Range for AIM 128 The scanner can be configured to only decode AIM 128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes AIM 128 barcodes with either the minimum or maximum length.
Page 84: Restore Default Settings
**【Enter Setup】 EAN-8 Restore Default Settings Scan the barcode below to restore all parameters in EAN-8 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of EAN-8】 Enable/Disable EAN-8 EAN-8 is enabled by default.
Page 85 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for EAN-8. To set the Code ID, scan the Set Code ID for EAN-8 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 86: Digit Add-On Code
**【Enter Setup】 2-Digit Add-On Code An EAN-8 barcode can be augmented with a two-digit add-on code to form a new one. **【Disable 2-Digit Add-On Code】【Enable 2-Digit Add-On Code】【Decode EAN-8 + 2-Digit Add-On Code Only】 Note:  Disable 2-Digit Add-On Code: The scanner decodes EAN-8 and ignores the add-on code when presented with an EAN-8 plus 2-digit add-on barcode.
Page 87: Digit Add-On Code
**【Enter Setup】 5-Digit Add-On Code An EAN-8 barcode can be augmented with a five-digit add-on code to form a new one. **【Disable 5-Digit Add-On Code】【Enable 5-Digit Add-On Code】【Decode EAN-8 + 5-Digit Add-On Code Only】 Note:  Disable 5-Digit Add-On Code: The scanner decodes EAN-8 and ignores the add-on code when presented with an EAN-8 plus 5-digit add-on barcode.
Page 88: Ean-8 Extension
**【Enter Setup】 EAN-8 Extension  Disable EAN-8 Zero Extend: Transmit EAN-8 barcodes as is.  Enable EAN-8 Zero Extend: Add five leading zeros to decoded EAN-8 barcodes to extend to13 digits.  Convert EAN-8 to EAN-13: Add five leading zeros to decoded EAN-8 barcodes to make them compatible in format to EAN-13 barcodes.
Page 89: Restore Default Settings
**【Enter Setup】 EAN-13 Restore Default Settings Scan the barcode below to restore all parameters in EAN-13 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of EAN-13】 Enable/Disable EAN-13 EAN-13 is enabled by default.
Page 90: Transmit Check Digit
**【Enter Setup】 Transmit Check Digit EAN-13 is 13 digits in length with the last one as its check digit used to verify the integrity of the data. By default, the scanner transmits EAN-13 check digit. **【Transmit EAN-13 Check Digit】【Do Not Transmit EAN-13 Check Digit】 Set Code ID Code ID can only consist of one or two English letters.
Page 91: Digit Add-On Code
**【Enter Setup】 2-Digit Add-On Code An EAN-13 barcode can be augmented with a two-digit add-on code to form a new one. **【Disable 2-Digit Add-On Code】【Enable 2-Digit Add-On Code】【Decode EAN-13 + 2-Digit Supplement Only】 Note:  Disable 2-Digit Add-On Code: The scanner decodes EAN-13 and ignores the add-on code when presented with an EAN-13 plus 2-digit add-on barcode.
Page 92: Digit Add-On Code
**【Enter Setup】 5-Digit Add-On Code An EAN-13 barcode can be augmented with a five-digit add-on code to form a new one. **【Disable 5-Digit Add-On Code】【Enable 5-Digit Add-On Code】【Decode EAN-13 + 5-Digit Add-On Code Only】 Note:  Disable 5-Digit Add-On Code: The scanner decodes EAN-13 and ignores the add-on code when presented with an EAN-13 plus 5-digit add-on barcode.
Page 93: Ean-13 Beginning With 290 Add-On Code Required
**【Enter Setup】 EAN-13 Beginning with 290 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “290”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “290” must have a 2-digit or 5-digit add-on code. The EAN-13 barcode with the add-on code is then transmitted.
Page 94: Ean-13 Beginning With 414/419 Add-On Code Required
**【Enter Setup】 EAN-13 Beginning with 414/419 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with a “414” or “419”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with a “414” or “419” must have a 2-digit or 5-digit add-on code. The EAN-13 barcode with the add-on code is then transmitted.
Page 95: Ean-13 Beginning With 977 Add-On Code Required
**【Enter Setup】 EAN-13 Beginning with 977 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “977”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “977” must have a 2-digit or 5-digit add-on code. The EAN-13 barcode with the add-on code is then transmitted.
Page 96: Ean-13 Beginning With 979 Add-On Code Required
**【Enter Setup】 EAN-13 Beginning with 979 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “979”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “979” must have a 2-digit or 5-digit add-on code. The EAN-13 barcode with the add-on code is then transmitted.
Page 97: Restore Default Settings
**【Enter Setup】 ISSN Restore Default Settings Scan the barcode below to restore all parameters in ISSN configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of ISSN】 Enable/Disable ISSN ISSN is disabled by default.
Page 98 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for ISSN. To set the Code ID, scan the Set Code ID for ISSN barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 99: Restore Default Settings
**【Enter Setup】 ISBN Restore Default Settings Scan the barcode below to restore all parameters in ISBN configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of ISBN】 Enable/Disable ISBN ISBN is disabled by default.
Page 100: Set Isbn Format
**【Enter Setup】 Set ISBN Format The default format is ISBN-13. **【ISBN-13】【ISBN-10】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for ISBN. To set the Code ID, scan the Set Code ID for ISBN barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 101: Restore Default Settings
**【Enter Setup】 UPC-E Restore Default Settings Scan the barcode below to restore all parameters in UPC-E configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of UPC-E】 Enable/Disable UPC-E UPC-E is enabled by default.
Page 102: Transmit Check Digit
**【Enter Setup】 Transmit Check Digit UPC-E is 8 digits in length with the last one as its check digit used to verify the integrity of the data. By default, the scanner transmits UPC-E check digit. **【Transmit UPC-E Check Digit】【Do Not Transmit UPC-E Check Digit】 Set Code ID Code ID can only consist of one or two English letters.
Page 103: Digit Add-On Code
**【Enter Setup】 2-Digit Add-On Code A UPC-E barcode can be augmented with a two-digit add-on code to form a new one. **【Disable 2-Digit Add-On Code】【Enable 2-Digit Add-On Code】【Decode UPC-E + 2-Digit Add-On Code Only】, Note:  Disable 2-Digit Add-On Code: The scanner decodes UPC-E and ignores the add-on code when presented with a UPC-E plus 2-digit add-on barcode.
Page 104: Digit Add-On Code
**【Enter Setup】 5-Digit Add-On Code A UPC-E barcode can be augmented with a five-digit add-on code to form a new one. **【Disable 5-Digit Add-On Code】【Enable 5-Digit Add-On Code】【Decode UPC-E + 5-Digit Add-On Code Only】 Note:  Disable 5-Digit Add-On Code: The scanner decodes UPC-E and ignores the add-on code when presented with a UPC-E plus 5-digit add-on barcode.
Page 105: Transmit Preamble Character
**【Enter Setup】 Transmit Preamble Character Preamble characters (Country Code and System Character) can be transmitted as part of a UPC-E barcode. Select one of the following options for transmitting UPC-E preamble to the host device: transmit system character only, transmit system character and country code (“0”...
Page 106: Upc-A
**【Enter Setup】 UPC-A Restore Default Settings Scan the barcode below to restore all parameters in UPC-A configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of UPC-A】 Enable/Disable UPC-A UPC-A is enabled by default.
Page 107 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for UPC-A. To set the Code ID, scan the Set Code ID for UPC-A barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 108: Transmit Check Digit
**【Enter Setup】 Transmit Check Digit UPC-A is 13 digits in length with the last one as its check digit used to verify the integrity of the data. By default, the scanner transmits UPC-A check digit. **【Transmit UPC-A Check Digit】【Do Not Transmit UPC-A Check Digit】 Transmit Preamble Character Preamble characters (Country Code and System Character) can be transmitted as part of a UPC-A barcode.
Page 109: Digit Add-On Code
**【Enter Setup】 2-Digit Add-On Code A UPC-A barcode can be augmented with a two-digit add-on code to form a new one. **【Disable 2-Digit Add-On Code】【Enable 2-Digit Add-On Code】【Decode UPC-A + 2-Digit Add-On Code Only】, Note:  Disable 2-Digit Add-On Code: The scanner decodes UPC-A and ignores the add-on code when presented with a UPC-A plus 2-digit add-on barcode.
Page 110: Digit Add-On Code
**【Enter Setup】 5-Digit Add-On Code A UPC-A barcode can be augmented with a five-digit add-on code to form a new one. **【Disable 5-Digit Add-On Code】【Enable 5-Digit Add-On Code】【Decode UPC-A + 5-Digit Add-On Code Only】 Note:  Disable 5-Digit Add-On Code: The scanner decodes UPC-A and ignores the add-on code when presented with a UPC-A plus 5-digit add-on barcode.
Page 111: Interleaved 2 Of 5
**【Enter Setup】 Interleaved 2 of 5 Restore Default Settings Scan the barcode below to restore all parameters in Interleaved 2 of 5 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Interleaved 2 of 5】...
Page 112 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Interleaved 2 of 5. To set the Code ID, scan the Set Code ID for Interleaved 2 of 5 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 113: Check Digit Verification
**【Enter Setup】 Check Digit Verification A check digit is optional for Interleaved 2 of 5 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. By default, the scanner does not transmit Interleaved 2 of 5 check digit after verification. ...
Page 114: Set Length Range For Interleaved 2 Of 5
**【Enter Setup】 Set Length Range for Interleaved 2 of 5 The scanner can be configured to only decode Interleaved 2 of 5 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes Interleaved 2 of 5 barcodes with either the minimum or maximum length.
Page 115: Disable/Enable Febraban
**【Enter Setup】 Disable/Enable Febraban **【Disable Febraban】【Enable Febraban, Do Not Expand】【Enable Febraban, Expand】【Exit Setup】...
Page 116: Itf-6
**【Enter Setup】 ITF-6 ITF-6 is a special kind of Interleaved 2 of 5 with a length of 6 characters and the last character as the check character. By default, ITF-6 is disabled. ITF-6 priority principle: For the Interleaved 2 of 5 barcodes with a length of 6 characters and the last character as the check character, the ITF-6 configurations shall take precedence over the Interleaved 2 of 5 settings.
Page 117 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for ITF-6. To set the Code ID, scan the Set Code ID for ITF-6 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 118: Itf-14
**【Enter Setup】 ITF-14 ITF-14 is a special kind of Interleaved 2 of 5 with a length of 14 characters and the last character as the check character. By default, ITF-14 is disabled. ITF-14 priority principle: For the Interleaved 2 of 5 barcodes with a length of 14 characters and the last character as the check character, the ITF-14 configurations shall take precedence over the Interleaved 2 of 5 settings.
Page 119 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for ITF-14. To set the Code ID, scan the Set Code ID for ITF-14 barcode, the numeric barcodes for the hexadecimal value of a desired ID and the Save barcode.
Page 120: Deutsche 14
**【Enter Setup】 Deutsche 14 Restore Default Settings Scan the barcode below to restore all parameters in Deutsche14 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Deutsche 14】 Enable/Disable Deutsche 14 Deutsche 14 is disabled by default.
Page 121 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Deutsche14. To set the Code ID, scan the Set Code ID for Deutsche14 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 122: Deutsche 12
**【Enter Setup】 Deutsche 12 Restore Default Settings Scan the barcode below to restore all parameters in Deutsche12 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Deutsche12】 Enable/Disable Deutsche 12 Deutsche12 is disabled by default.
Page 123 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Deutsche12. To set the Code ID, scan the Set Code ID for Deutsche 12 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 124: Coop 25 (Japanese Matrix 2 Of 5)
**【Enter Setup】 COOP 25 (Japanese Matrix 2 of 5) Restore Default Settings Scan the barcode below to restore all parameters in COOP 25 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of COOP 25】...
Page 125 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for COOP 25. To set the Code ID, scan the Set Code ID for COOP 25 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 126: Check Digit Verification
**【Enter Setup】 Check Digit Verification A check digit is optional for COOP 25 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. By default, check digit verification is disabled. ...
Page 127: Set Length Range For Coop 25
**【Enter Setup】 Set Length Range for COOP 25 The scanner can be configured to only decode COOP 25 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes COOP 25 barcodes with either the minimum or maximum length.
Page 128: Matrix 2 Of 5 (European Matrix 2 Of 5)
**【Enter Setup】 Matrix 2 of 5 (European Matrix 2 of 5) Restore Default Settings Scan the barcode below to restore all parameters in Matrix 2 of 5 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Matrix 2 of 5】...
Page 129 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Matrix 2 of 5. To set the Code ID, scan the Set Code ID for Matrix 2 of 5 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 130: Check Digit Verification
**【Enter Setup】 Check Digit Verification A check digit is optional for Matrix 2 of 5 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. By default, check digit verification is disabled. ...
Page 131: Set Length Range For Matrix 2 Of 5
**【Enter Setup】 Set Length Range for Matrix 2 of 5 The scanner can be configured to only decode Matrix 2 of 5 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes Matrix 2 of 5 barcodes with either the minimum or maximum length.
Page 132: Industrial 25
**【Enter Setup】 Industrial 25 Restore Default Settings Scan the barcode below to restore all parameters in Industrial 25 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Industrial 25】 Enable/Disable Industrial 25 Industrial 25 is enabled by default.
Page 133 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Industrial 25. To set the Code ID, scan the Set Code ID for Industrial 25 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 134: Check Digit Verification
**【Enter Setup】 Check Digit Verification A check digit is optional for Industrial 25 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. By default, the scanner transmits check digit after verification. ...
Page 135: Set Length Range For Industrial 25
**【Enter Setup】 Set Length Range for Industrial 25 The scanner can be configured to only decode Industrial 25 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes Industrial 25 barcodes with either the minimum or maximum length.
Page 136: Standard 25
**【Enter Setup】 Standard 25 Restore Default Settings Scan the barcode below to restore all parameters in Standard 25 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Standard 25】 Enable/Disable Standard 25 Standard 25 is enabled by default.
Page 137 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Standard 25. To set the Code ID, scan the Set Code ID for Standard 25 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 138: Check Digit Verification
**【Enter Setup】 Check Digit Verification A check digit is optional for Standard 25 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. By default, check digit verification is disabled. ...
Page 139: Set Length Range For Standard 25
**【Enter Setup】 Set Length Range for Standard 25 The scanner can be configured to only decode Standard 25 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes Standard 25 barcodes with either the minimum or maximum length.
Page 140: Restore Default Settings
**【Enter Setup】 Code 39 Restore Default Settings Scan the barcode below to restore all parameters in Code 39 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Code 39】 Enable/Disable Code 39 Code 39 is enabled by default.
Page 141 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Code 39. To set the Code ID, scan the Set Code ID for Code 39 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 142: Check Digit Verification
**【Enter Setup】 Check Digit Verification A check digit is optional for Code 39 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. By default, check digit verification is disabled. ...
Page 143: Transmit Start/Stop Character
**【Enter Setup】 Transmit Start/Stop Character Code 39 uses an asterisk (*) for both the start and the stop characters. You can choose whether or not to transmit the start/stop characters by scanning the appropriate barcode below. By default, the scanner transmits the start/stop characters.
Page 144: Set Length Range For Code 39
**【Enter Setup】 Set Length Range for Code 39 The scanner can be configured to only decode Code 39 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes Code 39 barcodes with either the minimum or maximum length.
Page 145: Enable/Disable Code 32
**【Enter Setup】 Enable/Disable Code 32 Code 32 is a variant of Code 39 used by the Italian pharmaceutical industry. Scan the appropriate bar code below to enable or disable Code 32. Code 39 must be enabled and Code 39 check digit verification must be disabled for this parameter to function.
Page 146: Transmit Code 32 Check Digit
**【Enter Setup】 Transmit Code 32 Check Digit Code 32 must be enabled for this parameter to function. **【Do Not Transmit Code 32 Check Digit】【Transmit Code 32 Check Digit】 Transmit Code 32 Start/Stop Character Code 32 must be enabled for this parameter to function. **【Do Not Transmit Code 32 Start/Stop Character】...
Page 147: Codabar
**【Enter Setup】 Codabar Restore Default Settings Scan the barcode below to restore all parameters in Codabar configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Codabar】 Enable/Disable Codabar Codabar is enabled by default.
Page 148 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Codabar. To set the Code ID, scan the Set Code ID for Codabar barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 149: Check Digit Verification
**【Enter Setup】 Check Digit Verification A check digit is optional for Codabar and can be added as the last digit. It is a calculated value used to verify the integrity of the data. By default, check digit verification is disabled. ...
Page 150: Start/Stop Character
**【Enter Setup】 Start/Stop Character By default, the scanner transmits start/stop characters which are in the form of “ABCD/ABCD”. 【Do not Transmit Start/Stop Character】 **【Transmit Start/Stop Character】 **【ABCD/ABCD As the Start/Stop Character】【ABCD/TN*E As the Start/Stop Character】【abcd/abcd As the Start/Stop Character】【abcd/tn*e As the Start/Stop Character】...
Page 151: Set Length Range For Codabar
**【Enter Setup】 Set Length Range for Codabar The scanner can be configured to only decode Codabar barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes Codabar barcodes with either the minimum or maximum length.
Page 152: Restore Default Settings
**【Enter Setup】 Code 93 Restore Default Settings Scan the barcode below to restore all parameters in Code 93 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Code 93】 Enable/Disable Code 93 Code 93 is enabled by default.
Page 153 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Code 93. To set the Code ID, scan the Set Code ID for Code 93 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 154: Check Digit Verification
**【Enter Setup】 Check Digit Verification Check digits are optional for Code 93 and can be added as the last two digits, which are calculated values used to verify the integrity of the data. By default, the scanner does not transmit check digits after verification. ...
Page 155: Set Length Range For Code 93
**【Enter Setup】 Set Length Range for Code 93 The scanner can be configured to only decode Code 93 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes Code 93 barcodes with either the minimum or maximum length.
Page 156: Restore Default Settings
**【Enter Setup】 Code 11 Restore Default Settings Scan the barcode below to restore all parameters in Code 11 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Code 11】 Enable/Disable Code 11 Code 11 is disabled by default.
Page 157 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Code 11. To set the Code ID, scan the Set Code ID for Code 11 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 158: Check Digit Verification
**【Enter Setup】 Check Digit Verification Check digits are optional for Code 11 and can be added as the last one or two digits, which are calculated values used to verify the integrity of the data. By default, the scanner does not transmit check digit after verification (One Check Digit, MOD11).
Page 159: Set Length Range For Code 11
**【Enter Setup】 Set Length Range for Code 11 The scanner can be configured to only decode Code 11 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes Code 11 barcodes with either the minimum or maximum length.
Page 160: Plessey
**【Enter Setup】 Plessey Restore Default Settings Scan the barcode below to restore all parameters in Plessey configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of Plessey】 Enable/Disable Plessey Plessey is disabled by default.
Page 161 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for Plessey. To set the Code ID, scan the Set Code ID for Plessey barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 162: Check Digit Verification
**【Enter Setup】 Check Digit Verification Check digits are optional for Plessey and can be added as the last two digits, which are calculated values used to verify the integrity of the data. By default, the scanner does not transmit check digits after verification. ...
Page 163: Set Length Range For Plessey
**【Enter Setup】 Set Length Range for Plessey The scanner can be configured to only decode Plessey barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes Plessey barcodes with either the minimum or maximum length.
Page 164: Msi-Plessey
**【Enter Setup】 MSI-Plessey Restore Default Settings Scan the barcode below to restore all parameters in MSI-Plessey configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of MSI-Plessey】 Enable/Disable MSI-Plessey MSI-Plessey is disabled by default.
Page 165 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for MSI-Plessey. To set the Code ID, scan the Set Code ID for MSI-Plessey barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 166: Check Digit Verification
**【Enter Setup】 Check Digit Verification Check digits are optional for MSI-Plessey and can be added as the last one or two digits, which are calculated values used to verify the integrity of the data. By default, the scanner does not transmit check digit after verification (One Check Digit, MOD10).
Page 167: Set Length Range For Msi-Plessey
**【Enter Setup】 Set Length Range for MSI-Plessey The scanner can be configured to only decode MSI-Plessey barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. If minimum length is set to be greater than maximum length, the scanner only decodes MSI-Plessey barcodes with either the minimum or maximum length.
Page 168: Gs1 Databar
**【Enter Setup】 GS1 Databar Restore Default Settings Scan the barcode below to restore all parameters in GS1 Databar configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of GS1 Databar】 Enable/Disable GS1 Databar GS1 Databar is enabled by default.
Page 169 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for GS1 Databar. To set the Code ID, scan the Set Code ID for GS1 Databar barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 170: Pdf417
**【Enter Setup】 PDF417 Restore Default Settings Scan the barcode below to restore all parameters in PDF417 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of PDF417】 Enable/Disable PDF417 PDF417 is enabled by default.
Page 171 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for PDF417. To set the Code ID, scan the Set Code ID for PDF417 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 172: Set Length Range For Pdf417
**【Enter Setup】 Set Length Range for PDF417 The scanner can be configured to only decode PDF417 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. Minimum length is not allowed to be greater than maximum length.
Page 173: Sample Barcodes
**【Enter Setup】 Sample Barcodes When reading a PDF417 barcode, you need to scan it horizontally from the top/bottom row of the barcode to the bottom/top. Apart from the influence of barcode density, consecutive horizontal scans are essential for accomplishing a good read. The greater the row height is, the easier it is to decode a PDF417 barcode.
Page 174: Micropdf417
**【Enter Setup】 MicroPDF417 Restore Default Settings Scan the barcode below to restore all parameters in PDF417 configuration to the factory default settings. To find the related default settings, see the “Default Parameters Table” section in Appendix. 【Restore the Default Settings of MicroPDF417】 Enable/Disable MicroPDF417 MicroPDF417 is disabled by default.
Page 175 **【Enter Setup】 Set Code ID Code ID can only consist of one or two English letters. See the “Code ID Table” section in Appendix to find the default Code ID for MicroPDF417. To set the Code ID, scan the Set Code ID for MicroPDF417 barcode, the numeric barcodes corresponding to the hexadecimal value of a desired ID and the Save barcode.
Page 176: Set Length Range For Micropdf417
**【Enter Setup】 Set Length Range for MicroPDF417 The scanner can be configured to only decode MicroPDF417 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. Minimum length is not allowed to be greater than maximum length.
Page 177: Sample Barcodes
**【Enter Setup】 Sample Barcodes When reading a MicroPDF417 barcode, you need to scan it horizontally from the top/bottom row of the barcode to the bottom/top. Apart from the influence of barcode density, consecutive horizontal scans are essential for accomplishing a good read. The greater the row height is, the easier it is to decode a MicroPDF417 barcode.
Page 178 **【Enter Setup】【abcdefghijklmnopqrstuvwxyz】【Exit Setup】...
Page 179: Chapter 7 Data Formatter
**【Enter Setup】 Chapter 7 Data Formatter Introduction You may use the Data Formatter to modify the scanner’s output. For example, you can use the Data Formatter to insert characters at certain points in barcode data or to suppress/ replace/ send certain characters in barcode data as it is scanned.
Page 180 **【Enter Setup】 Step 3: Select data format. Scan a numeric barcode 0 or 1 or 2 or 3 to set this to Format_0 or Format_1 or Format_2 or Format_3. Step 4: Select formatter command type. Specify what type of formatter commands will be used. Scan a numeric barcode 6 to select formatter command type 6. (See the “Formatter Command Type 6”...
Page 181: Programming With Serial Commands
**【Enter Setup】 Programming with Serial Commands A data format can also be created by serial commands sent from the host device. The maximum size of a command string is 128 characters (non-alphanumeric characters excluded). The syntax consists of the following elements: Start of command: “(“, 1 character.
Page 182: Enable Data Format
**【Enter Setup】 Enable Data Format After enabling the Data Formatter, you may select a data format you want to use by scanning the appropriate barcode below. **【Format_0】【Format_1】【Format_2】【Format_3】 Change Data Format for a Single Scan You can switch between data formats for a single scan. The next barcode is scanned using the data format selected here, then reverts to the format you have selected above.
Page 183: Enable/Disable Data Formatter
**【Enter Setup】 Enable/Disable Data Formatter When Data Formatter is disabled, the data format you have enabled becomes invalid. **【Disable Data Formatter】 You may wish to require the data to conform to a data format you have created. The following settings can be applied to your data format: Enable Data Formatter, Required, Keep Prefix/Suffix: Scanned data that meets your data format requirements is modified accordingly and gets outputted along with prefixes and suffixes (if prefix and suffix are enabled).
Page 184: Non-Match Error Beep
**【Enter Setup】【Enable Data Formatter, Required, Keep Prefix/Suffix】【Enable Data Formatter, Required, Drop Prefix/Suffix】【Enable Data Formatter, Not Required, Keep Prefix/Suffix】【Enable Data Formatter, Not Required, Drop Prefix/Suffix】 Non-Match Error Beep If Non-Match Error Beep is turned ON, the scanner generates an error beep when a barcode is encountered that does not match your required data format.
Page 185: Clear Data Format
**【Enter Setup】 Clear Data Format There are two methods to remove data format from your scanner: Delete one data format: Scan the Clear One barcode, a numeric barcode (0-3) and the Save barcode. For example, to delete Format_2, you should scan the Clear One barcode, the 2 barcode and the Save barcode Delete all data formats: Scan the Clear All barcode.
Page 186: Formatter Command Type 6
**【Enter Setup】 Formatter Command Type 6 Send Commands F1 Send all characters Syntax=F1xx (xx: The insert character’s hex value) Include in the output message all of the characters from the input message, starting from current cursor position, followed by an insert character. F2 Send a number of characters Syntax=F2nnxx (nn: The numeric value (00-99) for the number of characters;...
Page 187 **【Enter Setup】 F3 Send all characters up to a particular character Syntax=F3ssxx (ss: The particular character’s hex value; xx: The insert character’s hex value) Include in the output message all characters from the input message, starting with the character at the current cursor position and continuing to, but not including, the particular character “ss,”...
Page 188 **【Enter Setup】 F4 Insert a character multiple times Syntax=F4xxnn (xx: The insert character’s hex value; nn: The numeric value (00-99) for the number of times it should be sent) Send “xx” character “nn” times in the output message, leaving the cursor in the current position. E9 and F4 Example: Send all but the last characters, followed by 2 tabs Send all characters except for the last 8 from the barcode above, followed by 2 tabs.
Page 189: Move Commands
**【Enter Setup】 B3 and B4 Example: Insert the symbology name and length Send the symbology name and length before the barcode data from the barcode above. Break up these insertions with spaces. End with a carriage return. Command string: B3F42001B4F42001F10D B3 is the “Insert symbology name”...
Page 190 **【Enter Setup】 F5 Example: Move the cursor forward and send the data Move the cursor forward 3 characters, then send the rest of the barcode data from the barcode above. End with a carriage return. Command string: F503F10D F5 is the “Move the cursor forward a number of characters” command 03 is the number of characters to move the cursor F1 is the “Send all characters”...
Page 191: Search Commands
**【Enter Setup】 Search Commands F8 Search forward for a character Syntax＝F8xx (xx: The search character’s hex value) Search the input message forward for “xx” character from the current cursor position, leaving the cursor pointing to the “xx” character. F8 Example: Send barcode data that starts after a particular character Search for the letter “D”...
Page 192 **【Enter Setup】 B0 Search forward for a string Syntax=B0nnnnS (nnnn: The string length (up to 9999); S: The ASCII hex value of each character in the string) Search forward for “S” string from the current cursor position, leaving cursor pointing to “S” string. For example, B0000454657374 will search forward for the first occurrence of the 4-character string “Test.”...
Page 193 **【Enter Setup】 E6 Search forward for a non-matching character Syntax=E6xx (xx: The search character’s hex value) Search the input message forward for the first non-“xx” character from the current cursor position, leaving the cursor pointing to the non-“xx” character. E6 Example: Remove zeros at the beginning of barcode data This example shows a barcode that has been zero filled.
Page 194: Miscellaneous Commands
**【Enter Setup】 Miscellaneous Commands FB Suppress characters Syntax＝FBnnxxyy..zz (nn: The numeric value (00-15) for the number of suppressed characters; xxyy..zz: The hex value of the characters to be suppressed) Suppress all occurrences of up to 15 different characters, starting at the current cursor position, as the cursor is advanced by other commands.
Page 195 **【Enter Setup】 E4 Example: Replace zeros with CRs in barcode data If the barcode has characters that the host application does not want included, you can use the E4 command to replace those characters with something else. In this example, you will replace the zeros in the barcode above with carriage returns.
Page 196: Appendix
Appendix Factory Defaults Table Parameter Factory Default Remark General Settings Setup Mode Enabled Programming Barcode Data Do not send Scan Mode Manual Mode 00~15 (00: Infinite; 01~15: Decode Session Timeout 15 seconds 1~15sec) Timeout between Decodes 1 second 00~15 (0~7.5sec) Sensitivity High Sensibility Applicable to the Sense mode...
Page 197 Parameter Factory Default Remark Parity Check None RS-232 Stop Bits 1 bit RS-232 Flow Control None RS-232 Data Bits 8 bits RS-232 USB HID-KBW Enabled Keyboard Layout 1- US (English) USB HID-KBW USB HID-KBW Inter-Character Delay 00-15(0-75ms) Convert Case No Case Conversion USB HID-KBW Emulate ALT+Keypad Disabled...
Page 198 Parameter Factory Default Remark Maximum Length Minimum Length AIM128 AIM 128 Disabled Maximum Length Minimum Length EAN-8 EAN-8 Enabled Check Digit Transmit 2-Digit Add-On Code Disabled 5-Digit Add-On Code Disabled Decode EAN-8 + 2-digit Add-On Code Only Disabled Decode EAN-8 + 5-digit Add-On Code Only Disabled Extend to EAN-13 Disabled...
Page 199 Parameter Factory Default Remark EAN-13 Beginning with 434/439 Add-On Code Do Not Require Add-On Code Required EAN-13 Beginning with 977 Add-On Code Do Not Require Add-On Code Required EAN-13 Beginning with 978 Add-On Code Do Not Require Add-On Code Required EAN-13 Beginning with 979 Add-On Code Do Not Require Add-On Code Required...
Page 200 Parameter Factory Default Remark Decode UPC-A + 5-digit Add-On Code Only Disabled Transmit Preamble Character System character Interleaved 2 of 5 Interleaved 2 of 5 Enabled Check Digit Verification Enabled Check Digit Do not transmit Maximum Length Minimum Length Min. length supported: 5 Febraban Disabled ITF-6...
Page 201 Parameter Factory Default Remark Matrix 2 of 5 Enabled Check Digit Verification Disabled Check Digit Do not transmit Maximum Length Minimum Length Min. length supported: 3 Industrial 25 Industrial 25 Enabled Check Digit Verification Disabled Check Digit Do not transmit Maximum Length Minimum Length Min.
Page 202 Parameter Factory Default Remark Min. length supported: 4 (including Minimum Length start/stop characters and check digit) Codabar Codabar Enabled Check Digit Verification Disabled Check Digit Do not transmit ABCD/ABCD format Start/Stop Character Transmit Maximum Length Minimum Length Min. length supported: 2 Code 93 Code 93 Enabled...
Page 203 Parameter Factory Default Remark MSI-Plessey MSI-Plessey Disabled Check Digit Do not transmit Check Digit Verification 1 Check Digit, MOD10 Maximum Length Minimum Length Min. length supported: 3 GS1 Databar GS1 Databar Enabled PDF417 PDF 417 Enabled Maximum Length 2710 Minimum Length MicroPDF417 MicroPDF417 Disabled...
Page 204: Aim Id Table
AIM ID Table Symbology AIM ID Possible AIM ID Parameters Code 128 UCC/EAN-128 AIM 128 ISBT 128 EAN-8 EAN-13 EAN-13 with Addon ISSN ISBN UPC-E UPC-E with Addon UPC-A UPC-A with Addon Interleaved 2 of 5 0,1,3 ITF-6 ITF-14 Deutsche 14 Deutsche 12 COOP 25（Japanese Matrix 2 of 5）...
Page 205: Code Id Table
Code ID Table Symbology Code ID Code 128 UCC/EAN-128 AIM 128 ISBT 128 EAN-8 EAN-13 ISSN ISBN UPC-E UPC-A Interleaved 2 of 5 ITF-6 ITF-14 Deutsche 14 Deutsche 12 COOP 25（Japanese Matrix 2 of 5） Matrix 2 of 5(European Matrix 2 of 5) Industrial 25 Standard 25 Code 39...
Page 206: Ascii Table
ASCII Table Char (Null char.) (Start of Header) (Start of Text) (End of Text) (End of Transmission) (Enquiry) (Acknowledgment) (Bell) (Backspace) (Horizontal Tab) (Line Feed) (Vertical Tab) (Form Feed) (Carriage Return) (Shift Out) (Shift In) (Data Link Escape) (XON) (Device Control 1) (Device Control 2) (XOFF) (Device Control 3) (Device Control 4)
Page 207 (Exclamation Mark) " (Double Quote) (Number Sign) (Dollar Sign) (Percent) & (Ampersand) (Single Quote) (Left / Opening Parenthesis) (Right / Closing Parenthesis) (Asterisk) (Plus) (Comma) (Minus / Dash) (Dot) (Forward Slash) (Colon) (Semi-colon) < (Less Than) (Equal Sign) > (Greater Than) (Question Mark) (AT Symbol)
Page 208 (Left / Opening Bracket) (Back Slash) (Right / Closing Bracket) (Caret / Circumﬂex) (Underscore) (Grave Accent)
Page 209 (Left/ Opening Brace) (Vertical Bar) (Right/Closing Brace) (Tilde) (Delete)
Page 210: Ascii Function Key Mapping Table
ASCII Function Key Mapping Table ASCII Function ASCII Value (HEX) No Function Key Mapping Function Key Mapping (Null char.) Null Ctrl+2 (Start of Header) Keypad Enter Ctrl+A Caps Lock Ctrl+B (Start of Text) (End of Text) Null Ctrl+C Null Ctrl+D (End of Transmission) Null Ctrl+E...
Page 211 ASCII Function Key Mapping Table (Continued) The function key mappings of the last five characters in the previous table differ from one keyboard layout to another. Function Key Mapping Country/ Keyboard Layout United States Ctrl+[ Ctrl+\ Ctrl+] Ctrl+6 Ctrl+- Belgium Ctrl+[ Ctrl+<...
Page 212: Symbology Id Number
Symbology ID Number Symbology ID Number Code 128 UCC/EAN-128 EAN-8 EAN-13 UPC-E UPC-A Interleaved 2 of 5 ITF-14 ITF-6 Matrix 2 of 5 Code 39 Codabar Code 93 AIM-128 COOP 25 ISSN ISBN Industrial 25 Standard 25 Plessey Code11 MSI-Plessey GS1 Databar PDF417 MicroPDF417...
Page 213: Digit Barcodes
Digit Barcodes After scanning numeric barcode(s), you need to scan the Save barcode to save the data. 【0】【5】【1】【6】【2】【7】【3】【8】【4】【9】...
Page 214 【A】【B】【C】【D】【E】【F】...
Page 215: Save/Cancel Barcodes
Save/Cancel Barcodes After reading numeric barcode(s), you need to scan the Save barcode to save the data. If you scan the wrong digit(s), you can either scan the Cancel barcode and then start the configuration all over again, or scan the Delete the Last Digit barcode and then the correct digit, or scan the Delete All digits barcode and then the digits you want.
Page 216 Newland Auto-ID Tech. Co., Ltd. (Headquarters) 3F, Building A, No.1, Rujiang West Rd., Mawei, Fuzhou, Fujian, China 350015 Tel: +86 - (0) 591-83978605 Fax: +86 - (0) 591-83979216 E-mail: contact@nlscan.com Web: www.newlandaidc.com Newland Europe BV Rolweg 25, 4104 AV Culemborg, The Netherlands...
