CyberData 011395 Operation Manual page 61

2.3.6.3 Delayed DTMF
On the SIP Configuration page the dial out extension supports the addition of comma delimited
pauses and sending additional DTMF tones (using rfc2833). The first comma will pause three
seconds after a call is first established with a remote device. Subsequent commas will pause for 2
seconds. A pause of one second will be sent after each numerical digit.
Extension String
302
302,2
302,25,,,4,,1
Note
Operations Guide
Table 2-15. Examples of Dial-Out Extension Strings
Resulting Action
Dial out extension 302 and establish a call
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2'
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2', send out DTMF tone 5, wait 6 seconds, send out DTMF
tone 4, wait 4 seconds, send out DTMF tone 1
The maximum number of total characters in the dial-out field is 25.
931251F
Installing the Singlewire InformaCast Speaker
Configure the Speaker Parameters
CyberData Corporation
53
