Web Page Item
Scene
ADA Compliant
Slow Fade
Fast Fade
Slow Blink
Fast Blink
Color
Brightness
Red
Green
Blue
Operations Guide
Table 2-7. Device Configuration Parameters (continued)
Description
Use this section to select the strobe flashing behavior for the Singlewire
Broadcast.
Strobe will blink ON at the specified brightness for 150ms then OFF for
350ms during the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and
back to 0 over the course of about 3.5 seconds during the duration of the
event.
Strobe will increase in brightness from 0 to the specified brightness and
back to 0 over the course of about 1.5 seconds during the duration of the
event.
Strobe will blink ON at the specified brightness for one second then OFF
for one second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five times per
second during the duration of the event.
Select the desired color (only one may be chosen).
How bright the strobe will blink when there is a Singlewire Broadcast.
This is the maximum brightness for "fade" type scenes.
The red LED value for the Singlewire Broadcast.
The green LED value for the Singlewire Broadcast.
The blue LED value for the Singlewire Broadcast.
Use this button to preview the strobe flashing behavior for the
Singlewire Broadcast Strobe Settings.
Click on the Test Audio button to do an audio test. When the Test
Audio button is pressed, you will hear a voice message for testing the
device audio quality and volume.
Click on the Test Microphone button to do a microphone test. When the
Test Microphone button is pressed, the following occurs:
1. The device will immediately start recording 3 seconds of audio.
2. The device will beep (indicating the end of recording).
3. The device will play back the recorded audio.
Click on the Test Relay button to do a relay test.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of some of
the web page items. First click on the Toggle Help button, and you will
see a question mark (
Move the mouse pointer to hover over a question mark to see a short
description of a specific web page item.
931251F
Installing the Singlewire InformaCast Speaker
Configure the Speaker Parameters
) appear next to some of the web page items.
