CyberData 011395 Operation Manual page 59

Web Page Item
Button Settings
Dial Out Extension
Extension ID
Note
Note
2.3.6.1 Dial Out Extension Strings and DTMF Tones (using rfc2833)
On the
pauses and sending additional DTMF tones (using rfc2833). The first comma will pause three
seconds after a call is first established with a remote device. Subsequent commas will pause for 2
seconds. A pause of one second will be sent after each numerical digit.
Extension String
302
302,2
302,25,,,4,,1
Note
Operations Guide
Table 2-13. SIP Configuration Parameters (continued)
Description
Specify the extension the device will call when someone presses the Call button.
Enter up to 64 alphanumeric characters.
Note: For information about dial-out extension strings and DTMF tones, see
2.3.6.1, "Dial Out Extension Strings and DTMF Tones (using
A Caller identification string added to outbound calls. Enter up to 64 alphanumeric
characters.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of some of the web page
items. First click on the Toggle Help button, and you will see a question mark (
appear next to some of the web page items. Move the mouse pointer to hover over a
question mark to see a short description of a specific web page item.
You must click on the Save button and then the Reboot button for the changes to take
effect.
For specific server configurations, go to the following website address:
http://www.cyberdata.net/connecting-to-ip-pbx-servers/
SIP Configuration Page—Top, dial out extensions support the addition of comma delimited
Table 2-14. Examples of Dial-Out Extension Strings
Resulting Action
Dial out extension 302 and establish a call
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2'
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2', send out DTMF tone 5, wait 6 seconds, send out DTMF
tone 4, wait 4 seconds, send out DTMF tone 1
The maximum number of total characters in the dial-out field is 64.
931251F
Installing the Singlewire InformaCast Speaker
Configure the Speaker Parameters
rfc2833)".
CyberData Corporation
51
Section
)
