CyberData 011395 Operation Manual page 55

Web Page Item
Slow Blink
Fast Blink
Color
Brightness
Red
Green
Blue
SIP Call Strobe Settings
Blink Strobe during Call
Scene
ADA Compliant
Slow Fade
Fast Fade
Slow Blink
Fast Blink
Color
Brightness
Red
Green
Blue
MWI Strobe Settings
Blink Strobe on MWI
Scene
Operations Guide
Table 2-13. SIP Configuration Parameters (continued)
Description
Strobe will blink ON at the specified brightness for one second then OFF for one
second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five times per second during
the duration of the event.
Select desired color (only one may be chosen).
How bright the strobe will blink when there is a SIP Ring. This is the maximum
brightness for "fade" type scenes.
The red LED value for SIP Ring.
The green LED value for SIP Ring.
The blue LED value for SIP Ring.
Use this button to preview the strobe flashing behavior for the SIP Ring Strobe
Settings.
The following strobe settings will only appear if a CyberData Strobe product is
connected to your device. If a CyberData Strobe product is not connected to
your device, you will not see the strobe settings.
When selected, the Strobe will blink a scene during a call.
Select desired scene (only one may be chosen).
Strobe will blink ON at the specified brightness for 150ms then OFF for 350ms during
the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and back to 0 over
the course of about 3.5 seconds during the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and back to 0 over
the course of about 1.5 seconds during the duration of the event.
Strobe will blink ON at the specified brightness for one second then OFF for one
second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five times per second during
the duration of the event.
Select desired color (only one may be chosen).
How bright the strobe will blink when there is a SIP Call. This is the maximum
brightness for "fade" type scenes.
The red LED value for SIP Call.
The green LED value for SIP Call.
The blue LED value for SIP Call.
Use this button to preview the strobe flashing behavior for the SIP Call Strobe
Settings.
The following strobe settings will only appear if you are using the Strobe Kit. If
you are not using the Strobe Kit, you will not see the strobe settings.
When selected, the strobe will blink a scene when a voicemail is waiting for its
extension.
Select desired scene (only one may be chosen).
931251F
Installing the Singlewire InformaCast Speaker
Configure the Speaker Parameters
CyberData Corporation
47
