CyberData 011395 Operation Manual page 53

2. On the SIP page, enter values for the parameters indicated in
Note
Web Page Item
SIP Settings
Enable SIP Operation
Register with a SIP Server
Use Cisco SRST
Primary SIP Server
Primary SIP User ID
Primary SIP Auth ID
Primary SIP Auth Password
Backup SIP Server 1
Backup SIP User ID 1
Backup SIP Auth ID 1
Backup SIP Auth Password 1
Backup SIP Server 2
Backup SIP User ID 2
Backup SIP Auth ID 2
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-13. SIP Configuration Parameters
Description
When enabled, the device will transmit, receive, and process SIP messages according
to the configured SIP settings below.
When enabled, the device will attempt to register to the configured SIP Server(s) on
this page. To configure the device to send and receive point-to-point SIP calls, enable
SIP Operation and disable Register with a SIP Server (see
to-Point Configuration").
When enabled, the backup servers are handled according to Cisco SRST (Survivable
Remote Site Telephony). It is required for use in clustered Cisco Unified
Communications Manager topologies.
Enter the SIP server address as an IPv4 address in dotted decimal notation or a fully
qualified domain name. This parameter also becomes the host portion of the SIP-URI
for the device's extension on the primary SIP server. This field can accept entries of
up to 255 characters in length.
Specify the SIP User ID for the Primary SIP Server. This parameter becomes the user
portion of the SIP-URI for the device's extension on the primary SIP server. Enter up
to 64 alphanumeric characters.
Specify the Authenticate ID for the Primary SIP Server. This parameter is required for
SIP registration authentication. Enter up to 64 alphanumeric characters.
Specify the Authenticate Password for the Primary SIP Server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric characters.
Enter the backup SIP server address as an IPv4 address in dotted decimal notation or
a fully qualified domain name. This parameter also becomes the host portion of the
SIP-URI for the device's extension on the backup SIP server. This field can accept
entries of up to 255 characters in length.
Specify the SIP User ID for the first backup SIP Server. This parameter becomes the
user portion of the SIP-URI for the device's extension on the first backup SIP server.
Enter up to 64 alphanumeric characters.
Specify the Authenticate ID for the first backup SIP server. This parameter is required
for SIP registration authentication. Enter up to 64 alphanumeric characters.
Specify the Authenticate Password for the first backup SIP server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric characters.
Enter a second backup SIP server address as an IPv4 address in dotted decimal
notation or a fully qualified domain name. This parameter also becomes the host
portion of the SIP-URI for the device's extension on the second backup SIP server.
This field can accept entries of up to 255 characters in length.
Specify the SIP User ID for the second backup SIP Server. This parameter becomes
the user portion of the SIP-URI for the device's extension on the second backup SIP
server. Enter up to 64 alphanumeric characters.
Specify the Authenticate ID for the second backup SIP server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric characters.
931251F
Installing the Singlewire InformaCast Speaker
) in the following table shows which web page items will be defined
.
Configure the Speaker Parameters
Table 2-13.
Section 2.3.6.2, "Point-
CyberData Corporation
45
