CyberData 011395 Operation Manual page 41

Web Page Item
Enable Push to Talk
Prevent Call Termination
Blink Button LED on monitor call
InformaCast Settings
InformaCast Address
Microphone Settings
Microphone
Microphone Gain
Push to Talk Microphone Gain
Microphone Boost 1 (+20dB)
Microphone Boost 2 (+20dB)
Power Settings
802.3AT Mode
Force 802.3AT Mode (NOT recommended)
Auxiliary Power Supply
Relay Settings
Activate Relay with DTMF Code
Operations Guide
Table 2-7. Device Configuration Parameters (continued)
Description
This option is for noisy environments. When enabled, the microphone
will be muted normally. When the Call button is pressed and held, it will
unmute the microphone and allow the operator to send audio back.
Using Push to Talk prevents the operator from terminating a call by
pressing the Call button. The call must be terminated by the phone user.
When this option is enabled, a call cannot be terminated using the call
button.
Selecting this will cause the button LED blink during a monitor call.
Unselecting this will cause the speaker to give no indication that it is in a
monitor call.
Use this field to set the address of your Informacast server. This will
override any Informacast server addresses received via SLP or DHCP.
Enter "0.0.0.0" to use values received via SLP or DHCP. If using TFTP
for configuration, simply enter an IP address (eg. 10.0.1.195)If using
HTTP for configuration, enter the full URL to the path that contains the
configuration file. Do not input the file
name(eg.http://10.0.1.195:8081/InformaCast/resources/).
These settings will only appear if you are using the Talk-Back
Speaker. If you are not using the Talk-Back Speaker, you will see
the words NOT INSTALLED.
Displays the status of optional microphone.
Set the microphone gain level.
Set the microphone gain level for Push to Talk operation.
Enables one of two +20dB gain boosts on the microphone when
checked.
Enables one of two +20dB gain boosts on the microphone when
checked.
This device automatically detects if it is plugged into an 802.3AT (also
known as PoE Plus) power source. 802.3AT provides more power than
older 802.3AT power sources and allows this speaker to play audio at
higher volumes. If you are sure this speaker is connected to an 802.3AT
power source, but it is not being detected correctly, you can override the
automatic settings below.
Enable this option if you are sure this speaker is connected to an
802.3AT power source, but it is not being detected correctly (not
recommended).
This device can be connected to a +24VDC auxiliary power supply.
Check this box if this is how this speaker is being powered.
Activates the relay when the DTMF Activation Code is entered on the
phone during a SIP call with the device. RFC2833 DTMF payload types
are supported.
931251F
Installing the Singlewire InformaCast Speaker
Configure the Speaker Parameters
CyberData Corporation
33
