CyberData 011395 Operation Manual page 40

Web Page Item
Time Settings
Set Time with NTP Server on boot
NTP Server
Posix Timezone String
Periodically sync time with server
Time update period (in hours)
Current Time
Set Time Manually
Clock Settings
Clock Kit
Clock Brightness (0 - 14)
Use Ambient Light Sensor
Clock Colon Type
Use 24 Hour Time
Button Settings
Button Installed
Activate Relay On Button Press
Relay On Button Press Duration
Button Lit when Idle
Button Brightness (0-255)
Play Ringback Tone
Operations Guide
Table 2-7. Device Configuration Parameters (continued)
Description
When selected, the time is set with an external NTP server when the
device restarts.
Use this field to set the address (in IPv4 dotted decimal notation or as a
canonical name) for the NTP Server. This field can accept canonical
names of up to 64 characters in length.
See Section 2.3.4.1, "Time Zone Strings"
use the Posix Timezone String to specify time zone and daylight savings
time where applicable. Enter up to 63 characters.
When selected, the time is periodically updated with the NTP server at
the configured interval below.
The time interval after which the device will contact the NTP server to
update the time. Enter up to 4 digits.
Allows you to input the current time. (6 character limit)
Set the system time when NTP is not enabled. Format is HH:MM:SS
These settings will only appear if you are using the Clock Kit. If you
are not using the Clock Kit, you will see the words NOT
INSTALLED.
Displays the status of optional Clock Kit.
This setting allows you to select the clock brightness level (0-14).
This setting enables or disables the ambient light sensor.
This setting allows you to select the clock colon type.
When selected, the time will be show in 24 hour format on the optional
clock display.
When selected, the speaker is assumed to be wired to a push-to-talk
button. Button settings will be enabled and sensor settings will be
disabled. When not selected, the speaker is assumed to be wired to a
sensor. Sensor settings will be enabled and button settings will be
disabled.
When selected, the relay will be activated when the Call button is
pressed.
The length of time (in seconds) during which the relay will be activated
when the Call button is pressed. Enter up to 5 digits. A Relay on Button
Press Duration value of 0 will pulse the relay once when the Call button
is pressed.
When selected, the Call button LED is illuminated while the device is idle
(a call is not in progress).
The desired Call button LED brightness level. Acceptable values are 0-
255, where 0 is the dimmest and 255 is the brightest. Enter up to 3
digits.
When selected, the device will play a ringback tone (corresponds to
Ringback Tone on the Audiofiles page) out of the speaker while placing
an outbound call. The Ringback Tone will play until the call is answered.
931251F
Installing the Singlewire InformaCast Speaker
Configure the Speaker Parameters
for information about how to
CyberData Corporation
32
