CyberData 011395 Operation Manual page 42

Web Page Item
Relay Pulse Code
Relay Pulse Duration (in seconds)
Relay Activation Code
Relay Deactivation Code
Activate Relay During Ring
Activate Relay During Night Ring
Activate Relay While Call Active
Misc Settings
Device Name
Auto-Answer Incoming Calls
Beep on Init
Beep on Page
Disable HTTPS (NOT recommended)
Dual Speakers
RGB Strobe
Singlewire Broadcast Strobe Settings
Priority
Operations Guide
Table 2-7. Device Configuration Parameters (continued)
Description
DTMF code used to pulse the relay when entered on a phone during a
SIP call with the device. Relay will activate for Relay Pulse Duration
seconds then deactivate. Activate Relay with DTMF Code must be
enabled. Enter up to 25 digits (* and # are supported).
The length of time (in seconds) during which the relay will be activated
when the DTMF Relay Activation Code is detected. Enter up to 5 digits.
Activation code used to activate the relay when entered on a phone
during a SIP call with the device. Relay will be active indefinitely, or until
the DTMF Relay Deactivation code is entered. Activate Relay with
DTMF Code must be enabled. Enter up to 25 digits (* and # are
supported).
Code used to deactivate the relay when entered on a phone during a
SIP call with the device. Activate Relay with DTMF Code must be
enabled. Enter up to 25 digits (* and # are supported).
When selected, the relay will be activated for as long as the device is
ringing. When Auto-Answer Incoming Calls is enabled, the device will
not ring and this option does nothing.
When selected, the relay will be activated as long as the Nightringer
extension is ringing.
When selected, the relay will be activated as long as the SIP call is
active.
Type the device name. Enter up to 25 characters.
When selected, the device will automatically answer incoming calls.
When Auto-Answer Incoming Calls is disabled, the device will play a ring
tone (corresponds to Ring Tone on the Audiofiles page) out of the
speaker until someone presses the Call button to answer the call or the
caller disconnects before the call can be answered.
Device will play the user-defined "pagetone" audio file when it boots.
Device will play the user defined "pagetone" audio file before playing a
SIP page.
Disables the encrypted connection to the webpage. We do not
recommend disabling HTTPS for security reasons.
Select this option if two speakers (main and auxiliary) are connected to
the board.
Status of optional RGB Strobe.
For up to 10 Singlewire pages, when a priority is specified for the page,
a corresponding strobe scene will be activated. The color may be
selected from the drop down menu, or customized by the user with the
0-255 scale. Brightness is specified with a value between 0 and 100.
The following strobe settings will only appear if you are using the
Strobe Kit. If you are not using the Strobe Kit, you will not see the
strobe settings.
Indicates the priority of the Singlewire broadcast, with 1 the highest
priority and 10 the lowest.
931251F
Installing the Singlewire InformaCast Speaker
Configure the Speaker Parameters
CyberData Corporation
34
