3 Components and Power Supply
Green
Switch Ethernet interface LEDs
Fig. 4:
Below, you can find information on the LEDs associated to the Switch Ethernet interface:
Ethernet Switch interface LEDs table
LED
Orange
Green

3.1.2 Rear Panel

The following figure shows the rear panel.
Rear panel
Fig. 5:
The rear panel elements are as follows:
Rear panel connectors table
Item
A
B
C
D
6
Ethernet (link) connection established Off -> Link has not been detected
Description
Ethernet connection speed
Ethernet (link) connection established Off -> Link has not been detected
Description
Not supported.
SLOT 2: expansion slot for PMC-PCI cards. For further information, please see
section SLOT 2 - Expansion Slot
Not supported.
SLOT 3: Expansion slot for xDSL cards. For further information, please see sec-
tion SLOT 3 – Expansion Slot
Orange ->
10 Mbps: Flashes once
100 Mbps: Flashes twice
1000 Mbps: Flashes three times
Green -> Flashes depending on the
activity.
Status
Off -> Link has not been detected
Orange -> 10 Mbps: Flashes depend-
ing on the activity.
Green -> 100M bps: Flashes depend-
ing on the activity.
on page 11.
on page 13.
