3.2.3 SLOT 3 – Expansion Slot
SLOT 3 is located in the middle of the device's rear panel (see
board in this SLOT.
xDSL expansion card module
Fig. 21:
SLOT 3 elements table
Item
A
B
ATLAS 6x/i6x NW Router
Description.
Screws to hold the cover of the expansion module in SLOT 3.
xDSL expansion module.
Rear Panel on page 6). Insert an xDSL expansion
