A.4.4 Configuration Connector

RJ45 CONFIGURATION
A.5 Technical Specifications
A.5.1 Hardware Architecture
PROCESSOR
MEMORY
STORAGE UNIT
A.5.2 LAN Interfaces*
PROTOCOLS
Nº OF PORTS
SPEED
CONNECTORS
CABLE
*Depending on the model
A.5.3 Configuration Interface
LOCAL TERMINAL
CONNECTOR
ATLAS 6x/i6x NW Router
PIN
1
2
3
4
5
6
7
8
FreeScale QorlQ P1020E
512 Mbytes in DDR3
FLASH NOR Memory (64 Mbytes)
EEPROM 2Kbytes, NVRAM 128Kbytes
Ethernet (802.3)
3 (logical interfaces)
2x 10/100/1000 Mbps (BaseT) GEx
8x 10/100 Mbps (BaseT) Switch
RJ45 female
UTP, Cat 5
V.24 9600-8-N-1 without flow control
RJ45 female on the device's front panel
CONF
--
RxD
GND
--
--
GND
TxD
--
