Cable The Server To Connect To Oracle Ilom - Oracle X7 series Administration Manual

Management Management Port
Connection

Cable the Server to Connect to Oracle ILOM

Determine the type of connection to Oracle ILOM that best suits your
1.
environment.
For information about management connections to Oracle ILOM, see
Management Connection Options" on page
2. To establish a dedicated remote network management connection to Oracle
ILOM:
Connect an Ethernet cable between the NET MGT port on the server and the
a.
network switch.
DHCP and IPv6 stateless auto-configuration are enabled by default, allowing a DHCP
server on the network to automatically assign network settings to the service processor
(SP).
b. Determine the IP address assigned to the server SP.
Establish a serial connection to Oracle ILOM, and then view the properties under the
/network and /network/ipv6 hierarchies.
c. Type the IP address or host name into a browser address bar.
The Oracle ILOM Login dialog box appears.
For further instructions, see
Ethernet Connection" on page
3. To establish a local serial management connection to Oracle ILOM, perform the
following steps:
a. Connect a serial cable between the SER MGT port on the server and a
terminal device.
This connection provides your initial communication with the server service processor
(SP). Configure the terminal device with the following settings: 9600 baud, 8 data bits, 1
stop bit, and no parity (9600/8-N-1).
Description
The Host-to-ILOM Interconnect is also known as the Dedicated Interconnect SP
Note -
Management Connection.
"Launch and Log In to Oracle ILOM Through a Remote
24.

Cable the Server to Connect to Oracle ILOM

22.
Accessing and Using System Administration Tools
"Oracle ILOM
23
