CHAPTER 2: INSTALLATION
INPUT
SIGNAL
SWITCH
(WET)
EXTERNAL
DC POWER
SUPPLY

Output Relays

Table 2-6: Slots F,G,H Terminal Master Identifier (left) and I/O options A,A,N (right)
Slots F,G,H Terminal Master Identifier
Terminal #
SLOT F
1
RELAY_1
2
RELAY_1
3
RELAY_1
4
RELAY_2
5
RELAY_2
6
RELAY_2
7
RELAY_3
8
RELAY_3
9
RELAY_3
10
RELAY_4
11
RELAY_4
12
RELAY_4
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL
Figure 2-26: Wet and Dry Contact Input Wiring Examples
The locations of the output relays have a fixed assignment for the platform called the
master identifier. I/O options that include inputs occupy the fixed assigned output
locations so in these cases the relay assignment maps to the master identifier.
The critical failure output relay is reserved as Relay_8 and it is omitted and is not
programmable.
SLOT G
SLOT H
RELAY_9
RELAY_17
RELAY_9
RELAY_17
RELAY_9
RELAY_17
RELAY_10
RELAY_18
RELAY_10
RELAY_18
RELAY_10
RELAY_18
RELAY_11
RELAY_19
RELAY_11
RELAY_19
RELAY_11
RELAY_19
RELAY_12
RELAY_20
RELAY_12
RELAY_20
RELAY_12
RELAY_20
INPUT
SIGNAL
SWITCH
(DRY)
Slots F,G,H with I/O options A,A,N
Terminal #
SLOT F
1
RELAY_1
2
RELAY_1
3
RELAY_1
4
RELAY_2
5
RELAY_2
6
RELAY_2
7
RELAY_3
8
RELAY_3
9
RELAY_3
10
RELAY_4
11
RELAY_4
12
RELAY_4
ELECTRICAL INSTALLATION
SLOT G
RELAY_9
RELAY_9
RELAY_9
RELAY_10
RELAY_10
RELAY_10
RELAY_11
RELAY_11
RELAY_11
RELAY_12
RELAY_12
RELAY_12
2–23
