CHAPTER 2: INSTALLATION
Table 2-8: Slots F,G,H with I/O options A,A,F (left) and I/O options A, N, F (right)
Slots F,G,H with I/O options A,A,F
Terminal # SLOT F
1 RELAY_1
2 RELAY_1
3 RELAY_1
4 RELAY_2
5 RELAY_2
6 RELAY_2
7 RELAY_3
8 RELAY_3
9 RELAY_3
10 RELAY_4
11 RELAY_4
12 RELAY_4
13 Digital In_1
14 Digital In_2
15 Digital In_3
16 Digital In_4
17 Digital In_5
18 Digital In_6
19 Digital In_7
20 Common
21 +24V
22 RELAY_8
23 RELAY_8
24 RELAY_8
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL
SLOT G SLOT H
RELAY_9 Digital In_15
RELAY_9 Digital In_16
RELAY_9 Digital In_17
RELAY_10 Digital In_18
RELAY_10 Digital In_19
RELAY_10 Digital In_20
RELAY_11 Digital In_21
RELAY_11 Digital In_22
RELAY_11 Digital In_23
RELAY_12 Digital In_24
RELAY_12 Common
RELAY_12 +24V
Digital In_8 ARC
FLASHSensor
Digital In_9
1Sensor
2Sensor
Digital In_10
3Sensor 4
Digital In_11
Digital In_12
Digital In_13
Digital In_14
Common
+24V
RELAY_16
RELAY_16
RELAY_16
ELECTRICAL INSTALLATION
Slots F,G,H with I/O options A,N,F
Terminal # SLOT F
1 RELAY_1
2 RELAY_1
3 RELAY_1
4 RELAY_2
5 RELAY_2
6 RELAY_2
7 RELAY_3
8 RELAY_3
9 RELAY_3
10 RELAY_4
11 RELAY_4
12 RELAY_4
14 Digital In_2
15 Digital In_3
16 Digital In_4
17 Digital In_5
18 Digital In_6
19 Digital In_7
20 Common
21 +24V
22 RELAY_8
23 RELAY_8
24 RELAY_8
SLOT H
Digital In_8
Digital In_9
Digital In_10
Digital In_11
Digital In_12
Digital In_13
Digital In_14
Digital In_15
Digital In_16
Digital In_17
Common
+24V
ARC
FLASHSensor
1Sensor
2Sensor
3Sensor 4
