FREQUENCY

Frequency
6–8
Phase B Angle (Vbn Angle)
Range: 0.0 to 359.9°
Phase C Angle (Vcn Angle)
Range: 0.0 to 359.9°
Phase to Phase AB Angle (Vab Angle)
Range: 0.0 to 359.9°
Phase to Phase BC Angle (Vbc Angle)
Range: 0.0 to 359.9°
Phase to Phase CA Angle (Vca Angle)
Range: 0.0 to 359.9°
Neutral Angle (Vn Angle)
Range: 0.0 to 359.9°
Auxiliary Angle (Vaux Angle)
Range: 0.0 to 359.9°
Average Phase to Phase (V AVG L-L)
Range: 0.00 to 600000.00 V
Average Phase (V AVG L-N)
Range: 0.00 to 600000.00 V
Zero Sequence (V0) 0.00 V
Range: 0.00 to 600000.00 V
Positive Sequence (V1)
Range: 0.00 to 600000.00 V
Negative Sequence (V2)
Range: 0.00 to 600000.00 V
Zero Sequence Angle (V0 Angle)
Range: 0.0 to 359.9°
Positive Sequence Angle (V1 Angle)
Range: 0.0 to 359.9°
Negative Sequence Angle (V2 Angle)
Range: 0.0 to 359.9°
Path:
Metering > Frequency 1 - J
Frequency (Current Input J1-CT)
Range: 2.000 to 90.000 Hz
Frequency (Phase Voltage Input J2-3VT)
Range: 2.000 to 90.000 Hz
Frequency (Auxiliary Voltage Input J2-Vx)
Range: 2.000 to 90.000 Hz
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL
CHAPTER 6: METERING
