CHAPTER 6: METERING

Admittance

Neutral Admittance 1
Currents
NOTE:
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL
The effective operating quantities of the Neutral Impedance elements are displayed here.
Path:
Metering > Admittance > Neutral Admittance 1[X]
Ntrl Admit Mag
Range: 0.00 to 230,000.00 mS in steps of 0.01 mS
Default: 0.00 mS
This value represents the magnitude of the neutral admittance seen by the relay.
Ntrl Admit Angle
Range: -359.9° to 359.9° in steps of 0.1°
Default: 0.0°
This value represents the angle of the neutral admittance.
Ntrl Conductance
Range: -230,000.00 to 230,000.00 mS in steps of 0.01 mS
Default: 0.00 mS
This value represents the magnitude of the neutral admittance seen by the relay.
The number of Currents supported is order code dependent.
Path:
Metering > Currents
Phase A (Ia) 0.000 A
Range: 0.000 to 12000.000 A
Phase B (Ib)
Range: 0.000 to 12000.000 A
Phase C (Ic)
Range: 0.000 to 12000.000 A
Ground (Ig)
Range: 0.000 to 12000.000 A
Sensitive Ground (Isg)
Range: 0.000 to 1200.000 A
Neutral (In)
Range: 0.000 to 12000.000 A
Phase A (Ia RMS)
Range: 0.000 to 12000.000 A
Phase B (Ib RMS)
Range: 0.000 to 12000.000 A
ADMITTANCE
6–5
