Table 4-32: IAC CURVE TRIP TIMES (IN SECONDS)
MULTIPLIER CURRENT (I/I
(TDM)
1.5
IAC EXTREMELY INVERSE
0.5 1.699
1.0 3.398
2.0 6.796
4.0 13.591
6.0 20.387
8.0 27.183
10.0 33.979
IAC VERY INVERSE
0.5 1.451
1.0 2.901
2.0 5.802
4–118
MULTIPLIER CURRENT (I/I
(TDM)
1.5 2.0
0.05 0.153 0.089
0.10 0.306 0.178
0.20 0.612 0.356
0.40 1.223 0.711
0.60 1.835 1.067
0.80 2.446 1.423
1.00 3.058 1.778
IAC CURVES
The curves for the General Electric type IAC relay family are derived from the formula:
Where:
T = operate time (in seconds)
TDM = Multiplier setting
I = input current
I = Pickup Current setting
pickup
A to E = constants
t = characteristic constant
r
T = reset time in seconds (assuming energy capacity is 100% and RESET is
RESET
"Timed")
Table 4-31: GE TYPE IAC INVERSE TIME CURVE CONSTANTS
IAC CURVE SHAPE A
IAC Extremely Inverse 0.0040
IAC Very Inverse 0.0900
IAC Inverse 0.2078
IAC Short Inverse 0.0428
)
pickup
2.0 3.0 4.0
0.749 0.303 0.178
1.498 0.606 0.356
2.997 1.212 0.711
5.993 2.423 1.422
8.990 3.635 2.133
11.987 4.846 2.844
14.983 6.058 3.555
0.656 0.269 0.172
1.312 0.537 0.343
2.624 1.075 0.687
)
pickup
3.0 4.0 5.0
0.056 0.044 0.038
0.111 0.088 0.075
0.223 0.175 0.150
0.445 0.351 0.301
0.668 0.526 0.451
0.890 0.702 0.602
1.113 0.877 0.752
B C
0.6379 0.6200
0.7965 0.1000
0.8630 0.8000
0.0609 0.6200
5.0 6.0 7.0
0.123 0.093 0.074
0.246 0.186 0.149
0.491 0.372 0.298
0.983 0.744 0.595
1.474 1.115 0.893
1.966 1.487 1.191
2.457 1.859 1.488
0.133 0.113 0.101
0.266 0.227 0.202
0.533 0.453 0.405
