CHAPTER 4: SETPOINTS
NOTE:
NOTE:
WiFi Quick Start Procedure
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL
When choosing a new passphrase, the password complexity rules of CyberSentry must be
used (see CyberSentry details in the relay Instruction manual).
This field is visible only if the security is set to WPA2-PSK.
Ideally the passphrase should be set through EnerVista and not directly from the Keypad,
where there are limitations in terms of space and types of characters supported. However,
for convenience, the key setting is available from the Keypad as well.
WiFi Status
A WiFi symbol is displayed in the caption area of the 8-Series product front panel. The
following table lists all possibilities for this icon:
WiFi State
Disabled
Disconnected
Connecting
Connected
WiFi Events
Event
WiFi Connected
WiFi Disconnected
If the relay is in service mode and the settings are default a minor error is triggered.
The following provides the settings information and instructions to quickly setup WiFi.
Required Equipment
• 8-Series Relay with WiFi functionality
• PC with WiFi
• Access Point
Quick Start Procedure
1. The PC WiFi Network Settings are as follows:
Passphrase: provided with the 8-Series relay
2. The Access Point Settings are given below:
IP address: 192.168.0.1
Subnet Mask: 255.255.255.0
SSID: same as entered on the PC (SSID provided with the 8-Series relay)
Broadcast disabled
Security type: WPA2-PSK (WPA2-Personal)
Encryption: AES
Passphrase: same as entered on the PC (Passphrase provided with the 8-Series relay)
DHCP enabled range of 192.168.0.12 to 192.168.0.253
3. If the 8-Series relay(s) are in range, they automatically connect to the configured
Access Point.
WiFi Icon Color
Icon is grey and crossed by a red line
Grey
Yellow
Green
Description
This event is recorded to indicate a network connect.
This event is recorded to indicate a network
disconnect.
DEVICE
4–25
