CHAPTER 4: SETPOINTS

Ethernet Ports

Network Settings Menu
NOTE:
NOTE:
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL
The following communication offerings are available.
Base Offering
Modes: 10/100 Mbps
One Port: RJ45
Protocol: Modbus TCP
Communications Card Option "C" - 2x Copper (RJ45) Ports
Modes: 10/100 MB
Two Ports: RJ45 (with this option both enabled ports are on the communications card; the
Ethernet port located on the base CPU is disabled)
Protocols: Modbus TCP, DNP 3.0, IEC 60870-5-104, IEC 61850 GOOSE, IEEE 1588, SNTP, IEC
62439-3 clause 4 (PRP)
Communications Card Option "S" - 2x ST Fiber Ports
Modes: 100 MB
Two Ports: ST (with this option both enabled ports are on the communications card; the
Ethernet port located on the base CPU is disabled)
Protocols: Modbus TCP, DNP 3.0, IEC 60870-5-104, IEC 61850 GOOSE, IEEE 1588, SNTP, IEC
62439-3 clause 4 (PRP)
Wavelength: 1310 nm
Typical link distance: 4 km
The following are the network settings menu of the 850 to accommodate the features of
the 850 product. If the communications card is installed network port 1 is no longer
available. When using more than one Ethernet port, configure each to belong to a different
network or subnet using the IP addresses and mask, else communication becomes
unpredictable when more than one port is configured to the same subnet.
The softkeys and Down/Up key can be used to enter an IP address. When entering an IP
address you must press the "Back" key first to switch between softkey mode and the
Down/Up key mode.
NETWORK 1, 4, 5, PRT1(4,5) IP ADDRESS
Range: Standard IPV4 Address format
Default: 169.254.3.3 (Port 1)
Default: 127.0.0.1 (Port 4, 5)
The setting sets the port's IPV4 address in standard IPV4 format.
The setting is valid on port 1 if the optional communications card is not present.
The setting is valid on port 5 if port 4's OPERATION is set to INDEPENDENT.
PRT1(4,5) SUBNET IP MASK
Range: Standard IPV4 mask format
Default: 255.255.255.0 (Port 1)
Default: 0.0.0.0 (Port 4, 5)
This setting specifies the IPv4 mask associated with the corresponding port IP address.
PRT1 GWY ADDRESS
This setting sets the ports IPv4 GATEWAY address in standard IPv4 format.
This setting is only valid on port 1.
This setting is not present on port 4 and 5, which are available on the communications
card.
DEVICE
4–27
