7. Acquiring CEPH images

7.1 Setting Exposure Parameters

Perform the following procedures to select the capture parameters for the specific patient
and capture mode. Please refer to 4.3 Console Software for the more information.
❚

Steps for Configuring Imaging Conditions

ex) SC Sensor(Xmaru2301CF)
1. Click the CEPH button.
2. Select the examination program under Ceph Examination
3. (For One-shot CEPH only) Do the selections that follow.
— FOV Size: Select the FOV size.
FOV
Large
: 12x10 (inches)
: 30.48x25.40 (cm)


Details
Full size
82 I
PaX-i3D Smart
ex) OP Sensor(1210SGA)
Model
OP(1210SGA)
