3. Imaging System Overview

3.2 Imaging System Configuration

Exposure switch ch
Warning system panel
Warning lamp
PaX-i3D Smart
Fiber O Fiber Optice Cable 10m(32.8'): SCAN CEPH(Optional)
Etherne Ethernet Cable(CAT5e): OneShot CEPH(Optional)
Fiber O Fiber Optic Cable 10m(32.8'): PANO, CT
SIGNAL INPUT
WARNING SYSTEM BOX
LAMP INPUT LAMP OUTPUT
Door interlock
(Optional)
21 I
PaX-i3D Smart
PC w/ imaging and
image viewer programs
