13. Appendices

13.2 X-ray Dose Data

The X-ray dose data is extracted from the X-ray Dose Test Report for the
PaX-i3D Smart.
X-ray Dose Test Report for the PaX-i3D Smart maintains dosemetric evaluation of
VATECH dental diagnostic system meets all requirements specified in the IEC Collateral
Standard. To limit unnecessary exposure to the patient, operator or other staff, the PaX-
i3D Smart is designed to comply with IEC 60601-1-3 Part 1 General Requirements for
Safety.
Brand Name (Model)
Sensor type
X-ray generator
13.2.1

DAP Table

Instrument
Dose Meter
mA
[mGy]
kVp
60 6.25
70 9.29
80
12.57
90 15.33
Test Condition
PaX-i3D Smart(PHT-30LFO)
PANO/CT: Xmaru 1404CF
CEPH: Xmaru 2301CF(Scan Type)
DG-07C11T2
Test Equipment
Manufacturer Model
Piranha 205
Mode Tested: PANO Normal Adult 13.6s
6
[mGyㆍ
[mGy]
cm2]
40.50 9.33
60.20 12.37
81.45 15.65
99.34 18.41
135 I
PaX-i3D Smart
S/N
CB2-06100053
8
[mGyㆍ
[mGy]
cm2]
59.71 1260
79.17 15.64
100.16 18.92
117.82 21.68
10
[mGyㆍ
cm2]
81.65
98.75
122.60
140.49
