7. Acquiring CEPH images
3. Click the READY button. The x-ray exposure has not started yet.
4. Now go to 7.3 X-ray Exposure to begin operation.
7.3 X-ray Exposure
After alignment, the x-ray scan can begin.
The user must comply with the laws of the country regarding the usage of the
medical equipment.
Direct the patient to close their eyes during operation.
To acquire optimized images, direct the patient to hold their breath and to not
swallow. Also direct the patient to not move.
1. Direct the patient to close their eyes.
2. Close the door when leaving the x-ray room. Observe the patient during operation
and check the imaging status.
3. Begin acquisition by pressing the exposure switch. Continue to press the exposure
switch until the image has been acquired.
4. Release the exposure switch when "Image capturing is completed" message
appears on the screen.
Orange: X-ray On
