8. Acquiring CT Images
3. Begin acquisition by pressing the exposure switch.
Continue to press the exposure switch until the image has been acquired.
4. Release the exposure switch when "Image capturing is completed" message
appears on the screen.
During x-ray exposure, the status appears as follows.
● The exposure switch LED light is orange.
● The exposure switch LED light on top of the equipment is orange.
● An alert will sound to indicate that x-ray emission is currently underway.
● In the console software, the x-ray On in yellow changes.
Orange: X-ray On
