3. Imaging System Overview
No. Name
X-ray Sensor
1
(CEPH)
2 Nasal Positioner
3 Ear Rod
Secondary
4
Collimator
5 Vertical Frame
6 Rotating Unit
Enclosed
7 Component
Storage
8 X-ray Tube
9 Emergency Switch
Vertical Frame
10 Up/Down Switch
(optional)
11 Base (optional)
12 Stationary Column
13 Control Panel
CEPH imaging sensor (optional)
− 1-1. One shot Type
− 1-2. Scan Type
− Positions the patient during CEPH imaging.
− The ruler for use to compensate the acquired image
that is different from actual size.
Secure the patient's head during CEPH imaging.
Limits the X-ray irradiation field for CEPH scanning.
Holds the Rotating Unit.
Use the Vertical Frame Up/Down switch.
Rotates around the patient's head as image is being
acquired.
Movement depends on the scan mode.
Place where bite blocks, integrated chin rests and the
other components are stored.
The vacuum tube where the x-ray is produced.
Powers off the equipment when there is a problem
during operation.
Adjusts the height of the vertical frame.
Balances the equipment and maintains its safety.
A fixed column.
Operates the horizontal beam, opens/closes temple
supports, and adjusts the height of the vertical frame
and prepares for operation when the Ready button is
pressed.
24 I
PaX-i3D Smart
Function
