3. Imaging System Overview

3.1 Introduction

PaX-i3D Smart is an advanced digital dental diagnostic system that incorporates
Panoramic (PANO), Cephalometric (CEPH), and CBCT imaging capabilities into a single
system.
3.1.1

Intended Use

PaX-i3D Smart(PHT-30LFO) is a computed tomography x-ray system intended to
produce panoramic, cephalometric or cross-sectional images of the oral anatomy on
a real time basis by computer reconstruction of x-ray image data from the same axial
plane taken at different angles. It provides diagnostic details of the anatomic structures
by acquiring 360° rotational image sequences of oral and maxillofacial area for a precise
treatment planning in adult and pediatric dentistry . The device is operated and used by
physicians, dentists, and x-ray technicians.
3.1.2

System Components

● PaX-i3D Smart digital x-ray equipment
● PC system
● Imagaing Software
● EasyDent / EzDent-i: 2D viewer and patient management software
● Ez3D plus / Ez3D-i: 3D viewer and image analysis software
3.1.3 Features
● Low dose Imaging
● 3D Pan and Real 2D image acquisition by single scan
● 3D Viewer: 3D imaging supports precision analysis and diagnosis
● Supports the international digital imaging standard DICOM
