Table 2: Reader Programming Menus - Rosslare AYC-H6355 Installation And User Manual

Reader Functionality
Menu Description
1 Selecting Keypad Transmission Format
Single Key, 6-Bit Wiegand (Rosslare Format)
Single Key, 6-Bit Wiegand with Nibble + Parity Bits
Single Key, 8-Bit Wiegand, Nibbles Complemented
4 Keys Binary + Facility Code, Wiegand 26-Bit
1 to 5 Keys + Facility Code, Wiegand 26-Bit
6 Keys BCD and Parity Bits, Wiegand 26-Bit
1 to 8 Keys BCD, Clock & Data
Single Key, Wiegand 4-Bit
2 Selecting Card Transmission Format
Wiegand 26-Bit
Clock & Data
3 Changing the Programming Code
4 Changing the Facility Code
6 Backlight Options
Off
On (Default)
Off until key press when on for 10 seconds
Dimmed until key press when on for 10 seconds
0 Return to Factory Default Settings
20

Table 2: Reader Programming Menus

AYC-x6355 Installation and User Manual
Default
*
*
1234
0
*
